MLM1 NEMA 14 External Linear Step/direction input IP20

incl. 19% VAT

MLM1 NEMA 14 with

Pulse/Direction
Motion Control (RS485)
CANopen
Ethernet (MCode, Modbus TCP, Ethernet IP, Profinet I/O)

SKU: MLM1 NEMA 14-MLM1 NEMA 14 External Linear Step/direction input IP20 Category: Liberty/MDrives

Description

Description

MDrive Plus NEMA size 14 (36 mm) integrated stepper motor linear actuator. This is a Step/direction input with SPI interface for parameterization.
Holding torque range oz-in (N-cm): 18…36 (13 … 25)
I/O connector options: Wire Crimp
Com connector: IDC, Wire Crimp

Specification	MLM1 NEMA 14 External Linear Step/direction input IP20
Control type	Step/direction input
Feature set	–
P1 connector options	Wire Crimp Power & I/O
P2 connector options	IDC, Wire Crimp Comm
Communications interface	SPI
NEMA size	14 (36×36 mm)
Holding torque range	0.13 … 0.25 Nm
Temperature heatsink (short-time)	max. 85 °C
IP rating	IP20
Input voltage	+12 to +48 +VDC
Power supply current requirement	1.0 A

Parameter settings	MLM1 NEMA 14 External Linear Step/direction input IP20
Input Step, Direction & Enable voltage	–
Current	–
Digital Filter Range	10 … 38.8 MHz … kHz
Step Frequency	5 MHz Max
Microstep Resolutions	200 … 51200 Steps/Rev
Clock Types	–

Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
