| Characteristics | L1625N5M25-88-6.0 | L1625N5M35-60-5.0 | L1625N5M54-170-12.0 |
|---|---|---|---|
| Voltage | 6.0 V | 5.0 V | 12.0 V |
| Terminal resistance | 3.1 Ω | 4.4 Ω | 3.2 Ω |
| No-load speed | 8800 rpm | 6000 rpm | 18700 rpm |
| No-load current | 25 mA | 25 mA | 60 mA |
| Stall torque | 12.3 mNm | 8.6 mNm | 22.3 mNm |
| Stall current | 1935 mA | 1136 mA | 3750 mA |
| Load torque | 3.5 mNm | 1.0 mNm | 3.8 mNm |
| Load speed | 6290 rpm | 5310 rpm | 15470 rpm |
| Load current | 570 mA | 153 mA | 679 mA |
| Max. output power | 2.8 W | 1.4 W | 10.9 W |
| Max. efficiency | 79 % | 73 % | 76 % |
| Back-EMF constant | 0.67 mV/rpm | 0.82 mV/rpm | 0.63 mV/rpm |
| Torque constant | 6.43 mNm/A | 7.78 mNm/A | 6.03 mNm/A |
| Speed/torque gradient | 720 rpm/mNm | 690 rpm/mNm | 840 rpm/mNm |
| Rotor inertia | 0.7 g·cm² | 0.7 g·cm² | 0.7 g·cm² |
| Weight | 20.5 g | 20.5 g | 20.5 g |
| Operating temperature range | -20~+85 | -20~+85 | -20~+85 |
Applications
mini UAV
remote control hobby products
small household appliances
| Specification | L1625N5M25-88-6.0 |
|---|---|
| Voltage | 6.0 V |
| Terminal resistance | 3.1 Ω |
| No-load speed | 8800 rpm |
| No-load current | 25 mA |
| Stall torque | 12.3 mNm |
| Stall current | 1935 mA |
| Load torque | 3.5 mNm |
| Load speed | 6290 rpm |
| Load current | 570 mA |
| Max. output power | 2.8 W |
| Max. efficiency | 79 % |
| Back-EMF constant | 0.67 mV/rpm |
| Torque constant | 6.43 mNm/A |
| Speed/torque gradient | 720 rpm/mNm |
| Rotor inertia | 0.7 g·cm² |
| Weight | 20.5 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
| Specification | L1625N5M35-60-5.0 |
|---|---|
| Voltage | 5.0 V |
| Terminal resistance | 4.4 Ω |
| No-load speed | 6000 rpm |
| No-load current | 25 mA |
| Stall torque | 8.6 mNm |
| Stall current | 1136 mA |
| Load torque | 1.0 mNm |
| Load speed | 5310 rpm |
| Load current | 153 mA |
| Max. output power | 1.4 W |
| Max. efficiency | 73 % |
| Back-EMF constant | 0.82 mV/rpm |
| Torque constant | 7.78 mNm/A |
| Speed/torque gradient | 690 rpm/mNm |
| Rotor inertia | 0.7 g·cm² |
| Weight | 20.5 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
| Specification | L1625N5M54-170-12.0 |
|---|---|
| Voltage | 12.0 V |
| Terminal resistance | 3.2 Ω |
| No-load speed | 18700 rpm |
| No-load current | 60 mA |
| Stall torque | 22.3 mNm |
| Stall current | 3750 mA |
| Load torque | 3.8 mNm |
| Load speed | 15470 rpm |
| Load current | 679 mA |
| Max. output power | 10.9 W |
| Max. efficiency | 76 % |
| Back-EMF constant | 0.63 mV/rpm |
| Torque constant | 6.03 mNm/A |
| Speed/torque gradient | 840 rpm/mNm |
| Rotor inertia | 0.7 g·cm² |
| Weight | 20.5 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
