| Motor characteristics | L0616—06PP—L0616-1300-3.0-06PP25-0001 | L0616—06PP—L0615-1300-3.0-06PF25-0025 | L0616—06PP–L0615-1800-3.0-06PR25-0035 |
|---|---|---|---|
| Voltage | 3 V | 3 V | 3 V |
| Terminal resistance | 13.7 Ω | 13.7 Ω | 13.7 Ω |
| No-load speed | 1300 rpm | 1300 rpm | 1300 rpm |
| No-load current | 50 A | 50 A | 50 A |
| Max torque | 2.94 mNm | 2.94 mNm | 2.94 mNm |
| Load torque | 0.196 mNm | 0.196 mNm | 0.196 mNm |
| Load speed | 1210 rpm | 1210 rpm | 1210 rpm |
| Load current | 61 mA | 61 mA | 61 mA |
| Reduction ratio | 1/25 | 1/25 | 1/25 |
| Weight | 1.2 g | 1.2 g | 1.2 g |
| Operating temperature range | -10～+70 | -10～+70 | -10～+70 |
| Motor Characteristics | L0616—06PP—L0616-1300-3.0-06PP25-0001 | L0616—06PP—L0615-1300-3.0-06PF25-0025 | L0616—06PP–L0615-1800-3.0-06PR25-0035 |
|---|---|---|---|
| Voltage | – | 3 V | 3.0 V |
| Terminal resistance | – | 13.7 Ω | 7.8 Ω |
| No-load speed | – | 1300 rpm | 1750 rpm |
| No-load current | – | 50 A | 55 A |
| Max torque | – | 2.94 mNm | 3.4 mNm |
| Load torque | – | 0.196 mNm | 0.2 mNm |
| Load speed | – | 1200 rpm | 1680 rpm |
| Load current | – | 61 mA | 65 mA |
| Reduction ratio | – | 1/25 | 1/25 |
| Weight | – | 1.2 g | 1.2 g |
| Operating temperature range | – | -10～+70 | -10～+70 |
Applications
medical equipment
security systems and locks
audio and visual products
personal healthcare products
high-end hobby products
Produkt
| Specification | L0616—06PP—L0616-1300-3.0-06PP25-0001 |
|---|---|
| Voltage | 3 V |
| Terminal resistance | 13.7 Ω |
| No-load speed | 1300 rpm |
| No-load current | 50 A |
| Max torque | 2.94 mNm |
| Load torque | 0.196 mNm |
| Load speed | 1210 rpm |
| Load current | 61 mA |
| Reduction ratio | 1/25 |
| Weight | 1.2 g |
| Operating temperature range | -10～+70 °C |
Applications
medical equipment
security systems and locks
audio and visual products
personal healthcare products
high-end hobby products
Produkt
| Specification | L0616—06PP—L0615-1300-3.0-06PF25-0025 |
|---|---|
| Voltage | 3 V |
| Terminal resistance | 13.7 Ω |
| No-load speed | 1300 rpm |
| No-load current | 50 A |
| Max torque | 2.94 mNm |
| Load torque | 0.196 mNm |
| Load speed | 1200 rpm |
| Load current | 61 mA |
| Reduction ratio | 1/25 |
| Weight | 1.2 g |
| Operating temperature range | -10～+70 °C |
Applications
medical equipment
security systems and locks
audio and visual products
personal healthcare products
high-end hobby products
Produkt
| Specification | L0616—06PP–L0615-1800-3.0-06PR25-0035 |
|---|---|
| Voltage | 3.0 V |
| Terminal resistance | 7.8 Ω |
| No-load speed | 1750 rpm |
| No-load current | 55 A |
| Max torque | 3.4 mNm |
| Load torque | 0.2 mNm |
| Load speed | 1680 rpm |
| Load current | 65 mA |
| Reduction ratio | 1/25 |
| Weight | 1.2 g |
| Operating temperature range | -10～+70 °C |
Applications
medical equipment
security systems and locks
audio and visual products
personal healthcare products
high-end hobby products
