Description
1. Input power : DC12V – 48V
2. Output current : Rated 6A, Peak 18A
3. Supports brushless DC motors
4. 3 input channels, 2 output channels
5. Analog command
6. Supports RS485 communication protocol
| Parameter | Unit | DS-OLBD1-FRS4 |
|---|---|---|
| Size | (mm) | 118 × 75.5 × 25.5 |
| Operating Temperature | °C | 0 ~ 45°C |
| Storage Temperature | °C | -20 ~ 85°C |
| Operating Humidity | <85% RH | |
| Weight | g | 200 |
| Size | mm | 118 × 75.5 × 25.5 |
| Power Supply | DC | 12 – 24 |
| Drive motor | Brushless DC | |
| Speed Controlled Analog Voltage | V | 0 – 5 |
| Structure | Wall mounting | |
| Cooling Method | Air cooling | |
| Control Signal | Full isolation of input and output signals | |
| Protections | Over voltage, under voltage, over current, over temperature, abnormal hall signal and other fault alarms | |
| Communication Mode | RS-485 Multi-axes communication |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
