C1723R14-0096

The C1723R series is a compact 17mm coreless DC motor family with precious metal brushes, optimized for high efficiency and reliability. Operating at 6–7.4V, these motors deliver fast rotational speeds up to 19,400 rpm and support stall torques up to 7.57 mNm. Ideal for OEM integration in small electronics, security devices, model aircraft, and portable tools, with custom options for lead wires, shaft, coils, and gearheads.

SKU: C1723R14-0096 Category:

Description

C1723R Series – 17mm Coreless DC Motors with Precious Metal Brushes

The C1723R series delivers robust performance in a highly compact 17mm form factor, making it an excellent solution for demanding, space-sensitive applications. Featuring precious metal brushes, these motors combine long life, low electrical noise, and reliable commutation for precision control.

  • Voltage Range: 6.0–7.4 V DC
  • Maximum No-Load Speed: Up to 19,400 rpm
  • Stall Torque: Up to 7.57 mNm
  • Max. Efficiency: Up to 61.8%
  • Weight: 18.2 g
  • Operating Temperature: -20°C to +80°C
  • Integrated varistor for electrical protection

These motors are designed for integration into a variety of systems, including:

  • Security equipment and alarm systems
  • Small electronic and personal care devices
  • Remote control model aircraft
  • Portable electric tools

Standard customization options include lead wire length, shaft length, special coil configurations, and gearhead adaptation, enabling precise alignment with specific application requirements. With their efficient operation and flexible engineering options, the C1723R series is the preferred choice for high-precision, lightweight OEM solutions in consumer and industrial products.
