Description
Precious Metal Commutation
| Specification | C1718R134B-0059 |
|---|---|
| Voltage | 7.4 V |
| Terminal resistance | 3.0 Ω |
| No-load speed | 16000 rpm |
| No-load current | 70 mA |
| Stall torque | 6.53 mNm |
| Stall current | 1670 mA |
| Load torque | 0.49 mNm |
| Load speed | 14800 rpm |
| Load current | 190 mA |
| Max. output power | 2.74 W |
| Max. efficiency | 61.1 % |
| Back-EMF constant | 0.45 mV/rpm |
| Torque constant | 4.08 mNm/A |
| Speed/torque gradient | 2449 rpm/mNm |
| Varistor | Yes Yes/No |
| Weight | 14.5 g |
| Operating temperature range | -20~+60 °C |
Applications
security equipment
small electronic products
remote control model aircraft
personal care products
portable electric tools
