| Motor Characteristics | BO48**—52MP—BO4831NH2B01-101-18.0 | BO48**—52MP—BO4831NH2B02-101-24.0 | BO48**—52MP—BO4831NH2B03-101-36.0 |
|---|---|---|---|
| Voltage | 18.0 V | 24.0 V | 36.0 V |
| Terminal resistance | 0.05 Ω | 0.08 Ω | 0.18 Ω |
| No-load speed | 10160 rpm | 10160 rpm | 10160 rpm |
| No-load current | 1.1 mA | 0.9 mA | 0.6 mA |
| Stall torque | 6053 mNm | 6726 mNm | 6727 mNm |
| Stall current | 360 mA | 300 mA | 200 mA |
| Nominal torque | 449 mNm | 447 mNm | 457 mNm |
| Nominal speed | 7600 rpm | 7700 rpm | 7700 rpm |
| Nominal current | 23.5 mA | 17.6 mA | 12.0 mA |
| Max. output power | 1609 W | 1788 W | 1788 W |
| Max. efficiency | 89.2 % | 89.3 % | 89.3 % |
| Back-EMF constant | 1.8 mV/rpm | 2.4 mV/rpm | 3.5 mV/rpm |
| Torque constant | 16.9 mNm/A | 22.5 mNm/A | 33.7 mNm/A |
| Speed/torque gradient | 1.68 rpm/mNm | 1.51 rpm/mNm | 1.51 rpm/mNm |
| Rotor inertia | 306 g·cm² | 306 g·cm² | 306 g·cm² |
| Weight | 211 g | 211 g | 211 g |
| Gearbox characteristics | Produkt | ||
|---|---|---|---|
| Gearbox stages | 1 | ||
| Reduction ratio | 3.65~8.63 | ||
| Max. rated torque |
|
||
| Max. momentary torque |
|
||
| Length（L） |
|
||
| Gearbox stages | 2 | ||
| Reduction ratio | 28~58 | ||
| Max. rated torque |
|
||
| Max. momentary torque |
|
||
| Length（L） |
|
||
| Gearbox stages | 3 | ||
| Reduction ratio | 67~393 | ||
| Max. rated torque |
|
||
| Max. momentary torque |
|
||
| Length（L） |
|
Applications
medical equipment
scientific instruments
industrial equipment
Produkt
| Specification | BO48**—52MP—BO4831NH2B01-101-18.0 |
|---|---|
| Voltage | 18.0 V |
| Terminal resistance | 0.05 Ω |
| No-load speed | 10160 rpm |
| No-load current | 1.1 mA |
| Stall torque | 6053 mNm |
| Stall current | 360 mA |
| Nominal torque | 449 mNm |
| Nominal speed | 7600 rpm |
| Nominal current | 23.5 mA |
| Max. output power | 1609 W |
| Max. efficiency | 89.2 % |
| Back-EMF constant | 1.8 mV/rpm |
| Torque constant | 16.9 mNm/A |
| Speed/torque gradient | 1.68 rpm/mNm |
| Rotor inertia | 306 g·cm² |
| Weight | 211 g |
Applications
medical equipment
scientific instruments
industrial equipment
Produkt
| Specification | BO48**—52MP—BO4831NH2B02-101-24.0 |
|---|---|
| Voltage | 24.0 V |
| Terminal resistance | 0.08 Ω |
| No-load speed | 10160 rpm |
| No-load current | 0.9 mA |
| Stall torque | 6726 mNm |
| Stall current | 300 mA |
| Nominal torque | 447 mNm |
| Nominal speed | 7700 rpm |
| Nominal current | 17.6 mA |
| Max. output power | 1788 W |
| Max. efficiency | 89.3 % |
| Back-EMF constant | 2.4 mV/rpm |
| Torque constant | 22.5 mNm/A |
| Speed/torque gradient | 1.51 rpm/mNm |
| Rotor inertia | 306 g·cm² |
| Weight | 211 g |
Applications
medical equipment
scientific instruments
industrial equipment
Produkt
| Specification | BO48**—52MP—BO4831NH2B03-101-36.0 |
|---|---|
| Voltage | 36.0 V |
| Terminal resistance | 0.18 Ω |
| No-load speed | 10160 rpm |
| No-load current | 0.6 mA |
| Stall torque | 6727 mNm |
| Stall current | 200 mA |
| Nominal torque | 457 mNm |
| Nominal speed | 7700 rpm |
| Nominal current | 12.0 mA |
| Max. output power | 1788 W |
| Max. efficiency | 89.3 % |
| Back-EMF constant | 3.5 mV/rpm |
| Torque constant | 33.7 mNm/A |
| Speed/torque gradient | 1.51 rpm/mNm |
| Rotor inertia | 306 g·cm² |
| Weight | 211 g |
Applications
medical equipment
scientific instruments
industrial equipment
