| Specification | 2734ZDR-1-L2-30-3.7 | 2734ZDR-2-L13-30-3.7 | 2734ZDR-1-L3-25-5.0 |
|---|---|---|---|
| Voltage | 3.7 V | 3.7 V | 5.0 V |
| Resistance | 3.0 Ω | 2.5 Ω | 3.0 Ω |
| Operating frequency range | 100~240 | 100~240 | 100~240 |
| No-load vibration frequency | 30000 Times / minute | 30000 Times / minute | 30000 Times / minute |
| No-load current | 150 mA | 220 mA | 150 mA |
| Starting torque | 56 mNm | 56 mNm | 75 mNm |
| Starting current | 1.23 A | 1.48 A | 1.67 A |
| Rated load (Brush head) | 13.8 I 41 | 13.8 I 41 | 13.8 I 41 |
| Load vibration frequency | 20400 Times / minute | 20400 Times / minute | 20400 Times / minute |
| Load current | 580 mA | 630 mA | 670 mA |
| Rotor inertia | 2.4 g·cm² | 2.4 g·cm² | 2.4 g·cm² |
| Weight | 76 g | 76 g | 76 g |
| Operating temperature range | -10～+60 | -10～+60 | -10～+60 |
Applications
facial brushes
facial massagers
health care products
cleaning equipment
2734ZDR
| Specification | 2734ZDR-1-L2-30-3.7 |
|---|---|
| Voltage | 3.7 V |
| Resistance | 3.0 Ω |
| Operating frequency range | 100~240 Hz |
| No-load vibration frequency | 30000 Times / minute |
| No-load current | 150 mA |
| Starting torque | 56 mNm |
| Starting current | 1.23 A |
| Rated load (Brush head) | 13.8 I 41 g I mm |
| Load vibration frequency | 20400 Times / minute |
| Load current | 580 mA |
| Rotor inertia | 2.4 g·cm² |
| Weight | 76 g |
| Operating temperature range | -10～+60 °C |
Applications
facial brushes
facial massagers
health care products
cleaning equipment
2734ZDR
| Specification | 2734ZDR-2-L13-30-3.7 |
|---|---|
| Voltage | 3.7 V |
| Resistance | 2.5 Ω |
| Operating frequency range | 100~240 Hz |
| No-load vibration frequency | 30000 Times / minute |
| No-load current | 220 mA |
| Starting torque | 56 mNm |
| Starting current | 1.48 A |
| Rated load (Brush head) | 13.8 I 41 g I mm |
| Load vibration frequency | 20400 Times / minute |
| Load current | 630 mA |
| Rotor inertia | 2.4 g·cm² |
| Weight | 76 g |
| Operating temperature range | -10～+60 °C |
Applications
facial brushes
facial massagers
health care products
cleaning equipment
2734ZDR
| Specification | 2734ZDR-1-L3-25-5.0 |
|---|---|
| Voltage | 5.0 V |
| Resistance | 3.0 Ω |
| Operating frequency range | 100~240 Hz |
| No-load vibration frequency | 30000 Times / minute |
| No-load current | 150 mA |
| Starting torque | 75 mNm |
| Starting current | 1.67 A |
| Rated load (Brush head) | 13.8 I 41 g I mm |
| Load vibration frequency | 20400 Times / minute |
| Load current | 670 mA |
| Rotor inertia | 2.4 g·cm² |
| Weight | 76 g |
| Operating temperature range | -10～+60 °C |
Applications
facial brushes
facial massagers
health care products
cleaning equipment
