Brushed DC Motors

Brushed DC Motors can be easily controlled by applying a voltage. They are offered from diameters of 4mm to 153.5mm in the power range up to 2680W.

Brushed DC Motors are used in a wide variety of applications including power tools, fans, pumps, automotive applications and many other industrial and commercial applications.

Child categories:

29 products matching criteria

Sort:

|

View:

TC4 80 3A

Nominal Power Pn (ref. to 3000 rpm) 400W

Nominal Torque Mn (ref. to 3000 rpm) 1.27Nm

Peak torque Mmax 4.44Nm

Continuous working speed nM 6000rpm

Maximum working speed nMax 8000rpm

TC4 80 3B

Nominal Power Pn (ref. to 3000 rpm) 750W

Nominal Torque Mn (ref. to 3000 rpm) 2.38Nm

Peak torque Mmax 8.33Nm

Continuous working speed nM 6000rpm

Maximum working speed nMax 8000rpm

TC4 80 3C

Nominal Power Pn (ref. to 3000 rpm) 1000W

Nominal Torque Mn (ref. to 3000 rpm) 3.18Nm

Peak torque Mmax 11.10Nm

Continuous working speed nM 6000rpm

Maximum working speed nMax 8000rpm

TC4 60 2A

Nominal Power Pn (ref. to 3000 rpm) 200W

Nominal Torque Mn (ref. to 3000 rpm) 0.64Nm

Peak torque Mmax 2.24Nm

Continuous working speed nM 6000rpm

Maximum working speed nMax 8000rpm

TC4 60 2B

Nominal Power Pn (ref. to 3000 rpm) 400W

Nominal Torque Mn (ref. to 3000 rpm) 1.27Nm

Peak torque Mmax 4.44Nm

Continuous working speed nM 6000rpm

Maximum working speed nMax 8000rpm

1024N5M02-130-6.0

Terminal resistance 6.5Ω

No-load speed 13000rpm

No-load current 20mA

Stall torque 3.9mNm

1024N5M05-150-12.0

Terminal resistance 22.5Ω

No-load speed 15000rpm

No-load current 10mA

Stall torque 3.9mNm

1024N5M07-95-3.0

Terminal resistance 4.1Ω

No-load speed 9500rpm

No-load current 15mA

Stall torque 2.1mNm

1331N5M02-40-4.5

Terminal resistance 9.9Ω

No-load speed 4000rpm

No-load current 5mA

Stall torque 4.7mNm

1331N5M01-67-9.0

Terminal resistance 17.7Ω

No-load speed 6700rpm

No-load current 7mA

Stall torque 6.4mNm
