| Characteristics | 2225N5M01-161-7.2 | 2225N5M02-118-12.0 |
|---|---|---|
| Voltage | 7.2 V | 7.2 V |
| Terminal resistance | 1.9 Ω | 1.9 Ω |
| No-load speed | 16100 rpm | 16100 rpm |
| No-load current | 200 mA | 200 mA |
| Stall torque | 14.5 mNm | 14.5 mNm |
| Stall current | 3790 mA | 3790 mA |
| Nominal torque | 2.5 mNm | 2.5 mNm |
| Nominal speed | 13330 rpm | 13330 rpm |
| Nominal current | 820 mA | 820 mA |
| Max. output power | 6.1 W | 6.1 W |
| Max. efficiency | 59 % | 59 % |
| Back-EMF constant | 0.4 mV/rpm | 0.4 mV/rpm |
| Torque constant | 4.0 mNm/A | 4.0 mNm/A |
| Speed/torque gradient | 1109 rpm/mNm | 1109 rpm/mNm |
| Rotor inertia | 2.3 g·cm² | 2.3 g·cm² |
| Weight | 42.5 g | 42.5 g |
| Thermal resistance housing-ambient | 22.3 K/W | 22.3 K/W |
| Thermal resistance winding-housing | 28.4 K/W | 28.4 K/W |
| Thermal time constant motor | 313 s | 313 s |
| Thermal time constant winding | 218 s | 218 s |
| Operating temperature range | -20~+120 | -20~+120 |
| Thermal class of winding | 155 °C | 155 °C |
| Axial play | 0.02~0.15 | 0.02~0.15 |
| Radial play | 0.012 mm | 0.012 mm |
| Axial load dynamic | 2 N | 2 N |
| Axial load static | 150 N | 150 N |
| Radial load at 3 mm from mounting face | 4 N | 4 N |
| No. of pole pairs | 1 | 1 |
| Bearings | 2 sleeve bearings | 2 sleeve bearings |
| Commutator | metal 5 segments | metal 5 segments |
| Protection class | 40 IP | 40 IP |
Applications
medical equipment and devices
healthcare products
automotive
robotics
industrial automation
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | 2225N5M01-161-7.2 |
|---|---|
| Voltage | 7.2 V |
| Terminal resistance | 1.9 Ω |
| No-load speed | 16100 rpm |
| No-load current | 200 mA |
| Stall torque | 14.5 mNm |
| Stall current | 3790 mA |
| Nominal torque | 2.5 mNm |
| Nominal speed | 13330 rpm |
| Nominal current | 820 mA |
| Max. output power | 6.1 W |
| Max. efficiency | 59 % |
| Back-EMF constant | 0.4 mV/rpm |
| Torque constant | 4.0 mNm/A |
| Speed/torque gradient | 1109 rpm/mNm |
| Rotor inertia | 2.3 g·cm² |
| Weight | 42.5 g |
| Thermal resistance housing-ambient | 22.3 K/W |
| Thermal resistance winding-housing | 28.4 K/W |
| Thermal time constant motor | 313 s |
| Thermal time constant winding | 218 s |
| Operating temperature range | -20~+120 °C |
| Thermal class of winding | 155 °C |
| Axial play | 0.02~0.15 mm |
| Radial play | 0.012 mm |
| Axial load dynamic | 2 N |
| Axial load static | 150 N |
| Radial load at 3 mm from mounting face | 4 N |
| No. of pole pairs | 1 |
| Bearings | 2 sleeve bearings |
| Commutator | metal 5 segments |
| Protection class | 40 IP |
Applications
medical equipment and devices
healthcare products
automotive
robotics
industrial automation
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
