130mm Brushless DC Motor has Max. 8N·m rated torque and it can generate 837W capacity of rated power.
| Motor Characteristics | 130ZWS126LE-1 |
|---|---|
| Pole pair | 5 mm |
| Phase resistance | 1.68 Ω |
| Phase inductance | 1.036 mH |
| Winding connection method | Star shape |
| Insulation class | B |
| Duty type | S1 |
| Commutation angle | 120° |
| Insulation strength (Withstand voltage) | 1000VAC/1KHz/1mA/1s |
| Insulation resistance – 100 MOhm 20C | 100 MOhm 20C |
| Weight | 3.5 g |
| Rated voltage | 120 V |
| Rated power | 837.0 W |
| Rated torque | 8 mN·m |
| Rated speed | 1000 RPM |
| Rated current | 20 A |
| No load speed | 1300 RPM |
| No load current | 0.9 A |
| Motor efficiency | 94 % |
| Noise(Ambient noise 20db, test distance 1m) | ＜50 |
| Enclosure – Ambient thermal resistance K/W 0.9 | 0.22 K/W |
| Ambient temperature | 20 °C |
| Maximum winding temperature | 94 °C |
| Torque constant | 0.4 N·m/A |
| Back-EMF constant / Effective value | 94.2 V/Krpm |
| Peak torque | 24 mN·m |
| Peak current | 60 A |
| Inertia moment | 13.2 kg·cm² |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | 130ZWS126LE-1 |
|---|---|
| Pole pair | 5 mm |
| Phase resistance | 1.68 Ω |
| Phase inductance | 1.036 mH |
| Winding connection method | Star shape – |
| Insulation class | B – |
| Duty type | S1 – |
| Commutation angle | 120° – |
| Insulation strength (Withstand voltage) | 1000VAC/1KHz/1mA/1s – |
| Insulation resistance – 100 MOhm 20C | 100 MOhm 20C – |
| Weight | 3.5 g |
| Rated voltage | 120 V |
| Rated power | 837.0 W |
| Rated torque | 8 mN·m |
| Rated speed | 1000 RPM |
| Rated current | 20 A |
| No load speed | 1300 RPM |
| No load current | 0.9 A |
| Motor efficiency | 94 % |
| Noise(Ambient noise 20db, test distance 1m) | ＜50 dB |
| Enclosure – Ambient thermal resistance K/W 0.9 | 0.22 K/W |
| Ambient temperature | 20 °C |
| Maximum winding temperature | 94 °C |
| Torque constant | 0.4 N·m/A |
| Back-EMF constant / Effective value | 94.2 V/Krpm |
| Peak torque | 24 mN·m |
| Peak current | 60 A |
| Inertia moment | 13.2 kg·cm² |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
