General Specifications
| Parameter | Unit | MFM5 PowerDrive Step/direction Input |
|---|---|---|
| Control type | Step/Direction | |
| Control interface | Step, direction and enable inputs | |
| Driver type | Microstepping | |
| Operating temperature | °C | 2 |
| Input voltage | +VDC | +12 to +75 |
| Output voltage | A | 5.0 |
| Motion step frequency | MHz max | 2.5 |
| Motion step resolutions | steps/full step | 1 … 256 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
MFM5 PowerDrive Step/direction Input
MFM5 PowerDrive
MFM5 PowerDrive Step/direction Input
software
| Parameter | Unit | MFM5 PowerDrive Step/direction Input |
|---|---|---|
| Control type | Step/Direction | |
| Control interface | Step, direction and enable inputs | |
| Driver type | Microstepping | |
| Operating temperature | °C | 2 |
| Input voltage | +VDC | +12 to +75 |
| Output voltage | A | 5.0 |
| Motion step frequency | MHz max | 2.5 |
| Motion step resolutions | steps/full step | 1 … 256 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
