MFI1 MicroDrive
MFI1 MicroDrive with
- Pulse/Direction
- Motion Control (RS485)
- CANopen
- Ethernet (MCode, Modbus TCP, Ethernet IP, Profinet I/O)
General Specifications
| Parameter | Unit | MFI1 MicroDrive Programmable Motion Control | MFI1 MicroDrive CANopen |
|---|---|---|---|
| Control type | Programmable Motion | CANopen | |
| Control interface | Step, direction and enable inputs | Step, direction and enable inputs | |
| Driver type | Microstepping | Microstepping | |
| Operating temperature | °C | 2 | 2 |
| Input voltage | +VDC | +12 to +48 | +12 to +48 |
| Output voltage | A | 3.0 | 3.0 |
| Motion step frequency | MHz max | 2.5 | 2.5 |
| Motion step resolutions | steps/full step | 1 … 256 | 1 … 256 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
MFI1 MicroDrive Programmable Motion Control
MFI1 MicroDrive CANopen
MFI1 MicroDrive
MFI1 MicroDrive Programmable Motion Control
software
MFI1 MicroDrive CANopen
firmware
| Parameter | Unit | MFI1 MicroDrive Programmable Motion Control |
|---|---|---|
| Control type | Programmable Motion | |
| Control interface | Step, direction and enable inputs | |
| Driver type | Microstepping | |
| Operating temperature | °C | 2 |
| Input voltage | +VDC | +12 to +48 |
| Output voltage | A | 3.0 |
| Motion step frequency | MHz max | 2.5 |
| Motion step resolutions | steps/full step | 1 … 256 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
MFI1 MicroDrive Programmable Motion Control
MFI1 MicroDrive Programmable Motion Control
software
MFI1 MicroDrive
| Parameter | Unit | MFI1 MicroDrive CANopen |
|---|---|---|
| Control type | CANopen | |
| Control interface | Step, direction and enable inputs | |
| Driver type | Microstepping | |
| Operating temperature | °C | 2 |
| Input voltage | +VDC | +12 to +48 |
| Output voltage | A | 3.0 |
| Motion step frequency | MHz max | 2.5 |
| Motion step resolutions | steps/full step | 1 … 256 |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
