SKA Rotary Table
Stall Torque: 210 – 760 Nm
Peak Torque: 458 – 2400 Nm
Rated Speed: 70/100 rpm
Rated Volatage: 400 Vac
External Diameter (D): 490 mm
Holed Diameter (d): 290 mm
incl. VAT
SKA Rotary Table
Stall Torque: 210 – 760 Nm
Peak Torque: 458 – 2400 Nm
Rated Speed: 70/100 rpm
Rated Volatage: 400 Vac
External Diameter (D): 490 mm
Holed Diameter (d): 290 mm
Specification | SKA RT 430.30 56 | SKA RT 430.60 52 | SKA RT 430.60 56 | SKA RT 430.90 55 | SKA RT 430.90 56 | SKA RT 430.120 53 | SKA RT 430.150 66 | SKA RT 430.180 54 |
---|---|---|---|---|---|---|---|---|
Stall torque | 210 Nm | 340 Nm | 340 Nm | 450 Nm | 450 Nm | 560 Nm | 660 Nm | 760 Nm |
Peak torque | 458 Nm | 840 Nm | 840 Nm | 1200 Nm | 1200 Nm | 1600 Nm | 1900 Nm | 2400 Nm |
Rated torque | 175 Nm | 268 Nm | 268 Nm | 332 Nm | 332 Nm | 450 Nm | 520 Nm | 680 Nm |
Rated voltage | 400 Vac | 400 Vac | 400 Vac | 400 Vac | 400 Vac | 400 Vac | 400 Vac | 400 Vac |
Stall current | 9.07 Arms | 21.63 Arms | 14.68 Arms | 4.77 Arms | 19.43 Arms | 17.82 Arms | 17.73 Arms | 14.58 Arms |
Peak current | 27 Arms | 70 Arms | 47.5 Arms | 17.19 Arms | 70 Arms | 70 Arms | 70 Arms | 63.5 Arms |
Rated current | 7.78 Arms | 17.56 Arms | 11.92 Arms | 3.63 Arms | 14.77 Arms | 14.75 Arms | 14.39 Arms | 13.44 Arms |
Rated speed | 100 rpm | 100 rpm | 100 rpm | 60 rpm | 100 rpm | 100 rpm | 100 rpm | 100 rpm |
Maximum speed | 150 rpm | 150 rpm | 150 rpm | 70 rpm | 150 rpm | 150 rpm | 150 rpm | 110 rpm |
Torque constant | 23.16 Nm/Arms | 15.72 Nm/Arms | 23.16 Nm/Arms | 94.29 Nm/Arms | 23.16 Nm/Arms | 31.43 Nm/Arms | 37.22 Nm/Arms | 52.11 Nm/Arms |
Voltage constant | 1400 Vrms/krpm | 950 Vrms/krpm | 1400 Vrms/krpm | 5700 Vrms/krpm | 1400 Vrms/krpm | 1900 Vrms/krpm | 2250 Vrms/krpm | 3150 Vrms/krpm |
Phase/phase resistance | 3.25 Ω | 0.68 Ω | 1.47 Ω | 16.16 Ω | 0.98 Ω | 1.37 Ω | 1.64 Ω | 2.5 Ω |
Phase/phase inductance | 22.8 mH | 6.68 mH | 14.5 mH | 162 mH | 9.8 mH | 16 mH | 20 mH | 32 mH |
Electrical time constant | 7 msec | 9.9 msec | 9.9 msec | 10 msec | 10.1 msec | 11.7 msec | 12.2 msec | 12.8 msec |
Thermal resistance | 0.17 °C/W | 0.14 °C/W | 0.14 °C/W | 0.12 °C/W | 0.12 °C/W | 0.1 °C/W | 0.09 °C/W | 0.09 °C/W |
Mechanical time constant | 7.91 ms | 4.37 ms | 4.37 ms | 3.43 ms | 3.43 ms | 3.01 ms | 2.92 ms | 2.54 ms |
Max. theoretical acceleration | 527 rad/s2 | 790 rad/s2 | 790 rad/s2 | 954 rad/s2 | 954 rad/s2 | 1102 rad/s2 | 1155 rad/s2 | 1305 rad/s2 |
Rotor inertia | 8698 kg·cm² | 10637 kg·cm² | 10637 kg·cm² | 12577 kg·cm² | 12577 kg·cm² | 14516 kg·cm² | 16455 kg·cm² | 18394 kg·cm² |
Motor height H | 150 mm | 180 mm | 180 mm | 210 mm | 210 mm | 240 mm | 270 mm | 300 mm |
Motor weight | 105.7 Kg | 133.7 Kg | 133.7 Kg | 161.1 Kg | 161.1 Kg | 188.7 Kg | 215.7 Kg | 243.3 Kg |
Radial load | 7700 N(@30rpm) | 7700 N(@30rpm) | 7700 N(@30rpm) | 7700 N(@30rpm) | 7700 N(@30rpm) | 7700 N(@30rpm) | 7700 N(@30rpm) | 7700 N(@30rpm) |
Axial load | 6700 N(@60rpm) | 6700 N(@60rpm) | 6700 N(@60rpm) | 6700 N(@60rpm) | 6700 N(@60rpm) | 6700 N(@60rpm) | 6700 N(@60rpm) | 6700 N(@60rpm) |
Tilt moment | 800 N(@15rpm) | 800 N(@15rpm) | 800 N(@15rpm) | 800 N(@15rpm) | 800 N(@15rpm) | 800 N(@15rpm) | 800 N(@15rpm) | 800 N(@15rpm) |
Family Specification | Produkt |
---|---|
Time Rating | Continuous |
Insulation Class | F |
Enclosure | Totally enclosed, self-cooled |
Enclosure Rating | IP 42 (standard) |
Ambient temperature | 0 to 40 °C °C |
Ambient humidity | 20 to 80% RH (non condensing) |
Poles | 56 |
Thermal protection | PT 1000 |
Family Overview | Produkt |
---|---|
Stall Torque | 10 – 760 Nm |
Peak Torque | 458 – 2400 Nm |
Rated Speed | 70/100 rpm |
Rated Voltage | 400 Vac |
External Diameter (D) | 490 mm |
Hole Diameter (d) | 290 mm |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Specification | SKA RT 430.30 56 |
---|---|
Stall torque | 210 Nm |
Peak torque | 458 Nm |
Rated torque | 175 Nm |
Rated voltage | 400 Vac |
Stall current | 9.07 Arms |
Peak current | 27 Arms |
Rated current | 7.78 Arms |
Rated speed | 100 rpm |
Maximum speed | 150 rpm |
Torque constant | 23.16 Nm/Arms |
Voltage constant | 1400 Vrms/krpm |
Phase/phase resistance | 3.25 Ω |
Phase/phase inductance | 22.8 mH |
Electrical time constant | 7 msec |
Thermal resistance | 0.17 °C/W |
Mechanical time constant | 7.91 ms |
Max. theoretical acceleration | 527 rad/s2 |
Rotor inertia | 8698 kg·cm² |
Motor height H | 150 mm |
Motor weight | 105.7 Kg |
Radial load | 7700 N(@30rpm) |
Axial load | 6700 N(@60rpm) |
Tilt moment | 800 N(@15rpm) |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Specification | SKA RT 430.60 52 |
---|---|
Stall torque | 340 Nm |
Peak torque | 840 Nm |
Rated torque | 268 Nm |
Rated voltage | 400 Vac |
Stall current | 21.63 Arms |
Peak current | 70 Arms |
Rated current | 17.56 Arms |
Rated speed | 100 rpm |
Maximum speed | 150 rpm |
Torque constant | 15.72 Nm/Arms |
Voltage constant | 950 Vrms/krpm |
Phase/phase resistance | 0.68 Ω |
Phase/phase inductance | 6.68 mH |
Electrical time constant | 9.9 msec |
Thermal resistance | 0.14 °C/W |
Mechanical time constant | 4.37 ms |
Max. theoretical acceleration | 790 rad/s2 |
Rotor inertia | 10637 kg·cm² |
Motor height H | 180 mm |
Motor weight | 133.7 Kg |
Radial load | 7700 N(@30rpm) |
Axial load | 6700 N(@60rpm) |
Tilt moment | 800 N(@15rpm) |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Specification | SKA RT 430.60 56 |
---|---|
Stall torque | 340 Nm |
Peak torque | 840 Nm |
Rated torque | 268 Nm |
Rated voltage | 400 Vac |
Stall current | 14.68 Arms |
Peak current | 47.5 Arms |
Rated current | 11.92 Arms |
Rated speed | 100 rpm |
Maximum speed | 150 rpm |
Torque constant | 23.16 Nm/Arms |
Voltage constant | 1400 Vrms/krpm |
Phase/phase resistance | 1.47 Ω |
Phase/phase inductance | 14.5 mH |
Electrical time constant | 9.9 msec |
Thermal resistance | 0.14 °C/W |
Mechanical time constant | 4.37 ms |
Max. theoretical acceleration | 790 rad/s2 |
Rotor inertia | 10637 kg·cm² |
Motor height H | 180 mm |
Motor weight | 133.7 Kg |
Radial load | 7700 N(@30rpm) |
Axial load | 6700 N(@60rpm) |
Tilt moment | 800 N(@15rpm) |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Specification | SKA RT 430.90 55 |
---|---|
Stall torque | 450 Nm |
Peak torque | 1200 Nm |
Rated torque | 332 Nm |
Rated voltage | 400 Vac |
Stall current | 4.77 Arms |
Peak current | 17.19 Arms |
Rated current | 3.63 Arms |
Rated speed | 60 rpm |
Maximum speed | 70 rpm |
Torque constant | 94.29 Nm/Arms |
Voltage constant | 5700 Vrms/krpm |
Phase/phase resistance | 16.16 Ω |
Phase/phase inductance | 162 mH |
Electrical time constant | 10 msec |
Thermal resistance | 0.12 °C/W |
Mechanical time constant | 3.43 ms |
Max. theoretical acceleration | 954 rad/s2 |
Rotor inertia | 12577 kg·cm² |
Motor height H | 210 mm |
Motor weight | 161.1 Kg |
Radial load | 7700 N(@30rpm) |
Axial load | 6700 N(@60rpm) |
Tilt moment | 800 N(@15rpm) |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Specification | SKA RT 430.90 56 |
---|---|
Stall torque | 450 Nm |
Peak torque | 1200 Nm |
Rated torque | 332 Nm |
Rated voltage | 400 Vac |
Stall current | 19.43 Arms |
Peak current | 70 Arms |
Rated current | 14.77 Arms |
Rated speed | 100 rpm |
Maximum speed | 150 rpm |
Torque constant | 23.16 Nm/Arms |
Voltage constant | 1400 Vrms/krpm |
Phase/phase resistance | 0.98 Ω |
Phase/phase inductance | 9.8 mH |
Electrical time constant | 10.1 msec |
Thermal resistance | 0.12 °C/W |
Mechanical time constant | 3.43 ms |
Max. theoretical acceleration | 954 rad/s2 |
Rotor inertia | 12577 kg·cm² |
Motor height H | 210 mm |
Motor weight | 161.1 Kg |
Radial load | 7700 N(@30rpm) |
Axial load | 6700 N(@60rpm) |
Tilt moment | 800 N(@15rpm) |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Specification | SKA RT 430.120 53 |
---|---|
Stall torque | 560 Nm |
Peak torque | 1600 Nm |
Rated torque | 450 Nm |
Rated voltage | 400 Vac |
Stall current | 17.82 Arms |
Peak current | 70 Arms |
Rated current | 14.75 Arms |
Rated speed | 100 rpm |
Maximum speed | 150 rpm |
Torque constant | 31.43 Nm/Arms |
Voltage constant | 1900 Vrms/krpm |
Phase/phase resistance | 1.37 Ω |
Phase/phase inductance | 16 mH |
Electrical time constant | 11.7 msec |
Thermal resistance | 0.1 °C/W |
Mechanical time constant | 3.01 ms |
Max. theoretical acceleration | 1102 rad/s2 |
Rotor inertia | 14516 kg·cm² |
Motor height H | 240 mm |
Motor weight | 188.7 Kg |
Radial load | 7700 N(@30rpm) |
Axial load | 6700 N(@60rpm) |
Tilt moment | 800 N(@15rpm) |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Specification | SKA RT 430.150 66 |
---|---|
Stall torque | 660 Nm |
Peak torque | 1900 Nm |
Rated torque | 520 Nm |
Rated voltage | 400 Vac |
Stall current | 17.73 Arms |
Peak current | 70 Arms |
Rated current | 14.39 Arms |
Rated speed | 100 rpm |
Maximum speed | 150 rpm |
Torque constant | 37.22 Nm/Arms |
Voltage constant | 2250 Vrms/krpm |
Phase/phase resistance | 1.64 Ω |
Phase/phase inductance | 20 mH |
Electrical time constant | 12.2 msec |
Thermal resistance | 0.09 °C/W |
Mechanical time constant | 2.92 ms |
Max. theoretical acceleration | 1155 rad/s2 |
Rotor inertia | 16455 kg·cm² |
Motor height H | 270 mm |
Motor weight | 215.7 Kg |
Radial load | 7700 N(@30rpm) |
Axial load | 6700 N(@60rpm) |
Tilt moment | 800 N(@15rpm) |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Specification | SKA RT 430.180 54 |
---|---|
Stall torque | 760 Nm |
Peak torque | 2400 Nm |
Rated torque | 680 Nm |
Rated voltage | 400 Vac |
Stall current | 14.58 Arms |
Peak current | 63.5 Arms |
Rated current | 13.44 Arms |
Rated speed | 100 rpm |
Maximum speed | 110 rpm |
Torque constant | 52.11 Nm/Arms |
Voltage constant | 3150 Vrms/krpm |
Phase/phase resistance | 2.5 Ω |
Phase/phase inductance | 32 mH |
Electrical time constant | 12.8 msec |
Thermal resistance | 0.09 °C/W |
Mechanical time constant | 2.54 ms |
Max. theoretical acceleration | 1305 rad/s2 |
Rotor inertia | 18394 kg·cm² |
Motor height H | 300 mm |
Motor weight | 243.3 Kg |
Radial load | 7700 N(@30rpm) |
Axial load | 6700 N(@60rpm) |
Tilt moment | 800 N(@15rpm) |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
