Flange dimensions: 80 mm
Rated Output Power: 400 – 750 W
Rated Torque: 1,27 – 2,39 Nm
Rated Speed: 3000 rpm
| Specification | TC-E 80 3A D2 2 | TC-E 80 3B D4 2 | TC-E 80 3A D2 4 | TC-E 80 3B F3 4 |
|---|---|---|---|---|
| Continuous Stall Torque | 1.27 Nm | 2.39 Nm | 1.27 Nm | 2.39 Nm |
| Peak Torque | 3.81 Nm | 7.16 Nm | 3.81 Nm | 7.16 Nm |
| Nominal working Speed | 3000 rpm | 3000 rpm | 3000 rpm | 3000 rpm |
| Maximum working speed | 6000 rpm | 6000 rpm | 6000 rpm | 6000 rpm |
| Nominal Torque | 1.27 Nm | 2.39 Nm | 1.27 Nm | 2.39 Nm |
| Nominal Current | 2.52 Arms | 4.29 Arms | 2.52 Arms | 2.81 Arms |
| Nominal Power | 0.4 kW | 0.75 kW | 0.4 kW | 0.75 kW |
| Rated winding voltage | 230 Vac | 230 Vac | 400 Vac | 400 Vac |
| Maximum winding voltage | 360 Vdc | 360 Vdc | 650 Vdc | 650 Vdc |
| Maximum voltage to ground | 255 Vac | 255 Vac | 265 Vac | 265 Vac |
| Maximum current | 7.8 Arms | 13.5 Arms | 7.8 Arms | 8.66 Arms |
| Continuous Stall current | 2.29 Arms | 4.01 Arms | 2.29 Arms | 2.63 Arms |
| Voltage Constant | 33.5 Vrms/Krpm | 36 Vrms/Krpm | 33.5 Vrms/Krpm | 55 Vrms/Krpm |
| Torque Constant | 0.55 Nm/Arms | 0.6 Nm/Arms | 0.55 Nm/Arms | 0.91 Nm/Arms |
| Winding resistance | 3.2 Ω | 1.5 Ω | 3.2 Ω | 3.5 Ω |
| Winding inductance qu-v | 12 mH | 6.6 mH | 12 mH | 15.4 mH |
| Winding inductance du-v | 11.3 mH | 6.1 mH | 11.3 mH | 14.2 mH |
| Rotor inertia without holding brake | 0.66 kg·cm² | 1.18 kg·cm² | 0.66 kg·cm² | 1.18 kg·cm² |
| Rotor inertia with holding brake | 0.71 kg·cm² | 1.23 kg·cm² | 0.71 kg·cm² | 1.23 kg·cm² |
| Rotor high inertia without holding brake | – | 1.53 | – | 1.53 |
| Rotor high inertia with holding brake | – | 1.58 | – | 1.58 |
| Mass without holding brake | 2 Kg | 2.8 Kg | 2 Kg | 2.8 Kg |
| Mass with holding brake | 2.8 Kg | 3.6 Kg | 2.8 Kg | 3.6 Kg |
| High inertia mass without holding brake | – | 2.9 | – | 2.9 |
| High inertia mass with holding brake | – | 3.7 | – | 3.7 |
| Thermal time constant | 25 min | 28 min | 25 min | 28 min |
| Maximum radial shaft load | 332 N | 332 N | 332 N | 332 N |
| Maximum axial shaft load | 115 N | 115 N | 115 N | 115 N |
| Family Specification | Produkt |
|---|---|
| Time Rating | Continuous |
| Insulation Class | F |
| Enclosure | Totally enclosed. Self-cooled |
| Protection Class | IP 54 Standard IP 65 with shaft sealing |
| Ambient Temperature | -20 to 40 °C |
| Ambient Humidity | 5 to 85% (non-condensing) % |
| Poles | 8 |
| Certification | UL 1004, CSA, CE, RoHS, Reach compliance |
| Recommendation | Rated output with 250x250x12mm aluminum heat sink flange coupling – Ambient temperature 40°C – Derating must be considered if the oil seal is applied |
| Family Overview | Produkt |
|---|---|
| Flange dimensions | 80 mm |
| Rated Output Power | 400 – 750 Watt |
| Rated Torque | 1,27 – 2,39 Nm |
| Rated Speed | 3000 rpm |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
datasheet
| Specification | TC-E 80 3A D2 2 |
|---|---|
| Continuous Stall Torque | 1.27 Nm |
| Peak Torque | 3.81 Nm |
| Nominal working Speed | 3000 rpm |
| Maximum working speed | 6000 rpm |
| Nominal Torque | 1.27 Nm |
| Nominal Current | 2.52 Arms |
| Nominal Power | 0.4 kW |
| Rated winding voltage | 230 Vac |
| Maximum winding voltage | 360 Vdc |
| Maximum voltage to ground | 255 Vac |
| Maximum current | 7.8 Arms |
| Continuous Stall current | 2.29 Arms |
| Voltage Constant | 33.5 Vrms/Krpm |
| Torque Constant | 0.55 Nm/Arms |
| Winding resistance | 3.2 Ω |
| Winding inductance qu-v | 12 mH |
| Winding inductance du-v | 11.3 mH |
| Rotor inertia without holding brake | 0.66 kg·cm² |
| Rotor inertia with holding brake | 0.71 kg·cm² |
| Rotor high inertia without holding brake | – |
| Rotor high inertia with holding brake | – |
| Mass without holding brake | 2 Kg |
| Mass with holding brake | 2.8 Kg |
| High inertia mass without holding brake | – |
| High inertia mass with holding brake | – |
| Thermal time constant | 25 min |
| Maximum radial shaft load | 332 N |
| Maximum axial shaft load | 115 N |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
datasheet
| Specification | TC-E 80 3B D4 2 |
|---|---|
| Continuous Stall Torque | 2.39 Nm |
| Peak Torque | 7.16 Nm |
| Nominal working Speed | 3000 rpm |
| Maximum working speed | 6000 rpm |
| Nominal Torque | 2.39 Nm |
| Nominal Current | 4.29 Arms |
| Nominal Power | 0.75 kW |
| Rated winding voltage | 230 Vac |
| Maximum winding voltage | 360 Vdc |
| Maximum voltage to ground | 255 Vac |
| Maximum current | 13.5 Arms |
| Continuous Stall current | 4.01 Arms |
| Voltage Constant | 36 Vrms/Krpm |
| Torque Constant | 0.6 Nm/Arms |
| Winding resistance | 1.5 Ω |
| Winding inductance qu-v | 6.6 mH |
| Winding inductance du-v | 6.1 mH |
| Rotor inertia without holding brake | 1.18 kg·cm² |
| Rotor inertia with holding brake | 1.23 kg·cm² |
| Rotor high inertia without holding brake | 1.53 |
| Rotor high inertia with holding brake | 1.58 |
| Mass without holding brake | 2.8 Kg |
| Mass with holding brake | 3.6 Kg |
| High inertia mass without holding brake | 2.9 |
| High inertia mass with holding brake | 3.7 |
| Thermal time constant | 28 min |
| Maximum radial shaft load | 332 N |
| Maximum axial shaft load | 115 N |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
datasheet
| Specification | TC-E 80 3A D2 4 |
|---|---|
| Continuous Stall Torque | 1.27 Nm |
| Peak Torque | 3.81 Nm |
| Nominal working Speed | 3000 rpm |
| Maximum working speed | 6000 rpm |
| Nominal Torque | 1.27 Nm |
| Nominal Current | 2.52 Arms |
| Nominal Power | 0.4 kW |
| Rated winding voltage | 400 Vac |
| Maximum winding voltage | 650 Vdc |
| Maximum voltage to ground | 265 Vac |
| Maximum current | 7.8 Arms |
| Continuous Stall current | 2.29 Arms |
| Voltage Constant | 33.5 Vrms/Krpm |
| Torque Constant | 0.55 Nm/Arms |
| Winding resistance | 3.2 Ω |
| Winding inductance qu-v | 12 mH |
| Winding inductance du-v | 11.3 mH |
| Rotor inertia without holding brake | 0.66 kg·cm² |
| Rotor inertia with holding brake | 0.71 kg·cm² |
| Rotor high inertia without holding brake | – |
| Rotor high inertia with holding brake | – |
| Mass without holding brake | 2 Kg |
| Mass with holding brake | 2.8 Kg |
| High inertia mass without holding brake | – |
| High inertia mass with holding brake | – |
| Thermal time constant | 25 min |
| Maximum radial shaft load | 332 N |
| Maximum axial shaft load | 115 N |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
datasheet
| Specification | TC-E 80 3B F3 4 |
|---|---|
| Continuous Stall Torque | 2.39 Nm |
| Peak Torque | 7.16 Nm |
| Nominal working Speed | 3000 rpm |
| Maximum working speed | 6000 rpm |
| Nominal Torque | 2.39 Nm |
| Nominal Current | 2.81 Arms |
| Nominal Power | 0.75 kW |
| Rated winding voltage | 400 Vac |
| Maximum winding voltage | 650 Vdc |
| Maximum voltage to ground | 265 Vac |
| Maximum current | 8.66 Arms |
| Continuous Stall current | 2.63 Arms |
| Voltage Constant | 55 Vrms/Krpm |
| Torque Constant | 0.91 Nm/Arms |
| Winding resistance | 3.5 Ω |
| Winding inductance qu-v | 15.4 mH |
| Winding inductance du-v | 14.2 mH |
| Rotor inertia without holding brake | 1.18 kg·cm² |
| Rotor inertia with holding brake | 1.23 kg·cm² |
| Rotor high inertia without holding brake | 1.53 |
| Rotor high inertia with holding brake | 1.58 |
| Mass without holding brake | 2.8 Kg |
| Mass with holding brake | 3.6 Kg |
| High inertia mass without holding brake | 2.9 |
| High inertia mass with holding brake | 3.7 |
| Thermal time constant | 28 min |
| Maximum radial shaft load | 332 N |
| Maximum axial shaft load | 115 N |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
