Flange dimensions: 80 mm
Rated Output Power: 480 – 1068 W
Rated Torque: 1,53 – 3,4 Nm
Rated Speed: 3000 rpm
| Specification | TC-X 80 1,5 21 | TC-X 80 1,5 15 | TC-X 80 2,8 21 | TC-X 80 2,8 15 | TC-X 80 4 15 | TC-X 80 4 17 |
|---|---|---|---|---|---|---|
| Continous Stall Torque (ambient temperature 0 to +40°C) | 1.74 Nm | 1.74 Nm | 2.96 Nm | 2.96 Nm | 4 Nm | 4 Nm |
| Peak Torque (ambient temperature 0 to +40°C) | 4.5 Nm | 4.5 Nm | 8.4 Nm | 8.4 Nm | 12 Nm | 12 Nm |
| Nominal Torque (ambient temperature 0 to +40°C) | 1.53 Nm | 1.53 Nm | 2.55 Nm | 2.55 Nm | 3.4 Nm | 3.4 Nm |
| Rated Voltage (ambient temperature 0 to +40°C) | 230 Vdc | 400 Vdc | 230 Vdc | 400 Vdc | 230 Vdc | 400 Vdc |
| Nominal power (ambient temperature 0 to +40°C) | 480 W | 480 W | 800 W | 800 W | 1068 W | 1068 W |
| Continuous stall Current (ambient temperature 0 to +40°C) | 3.31 Arms | 1.91 Arms | 5.36 Arms | 3.25 Arms | 4.4 Arms | 2.5 Arms |
| Maximun Current (ambient temperature 0 to +40°C) | 8.55 Arms | 4.95 Arms | 15.97 Arms | 9.23 Arms | 13.19 Arms | 7.5 Arms |
| Nominal Current (ambient temperature 0 to +40°C) | 2.99 Arms | 1.73 Arms | 4.99 Arms | 2.88 Arms | 3.85 Arms | 2.19 Arms |
| Nominal working Speed (ambient temperature 0 to +40°C) | 3000 rpm | 3000 rpm | 3000 rpm | 3000 rpm | 3000 rpm | 3000 rpm |
| Maximum working speed 230VAC (ambient temperature 0 to +40°C) | 5000 rpm | 3900 rpm | 5000 rpm | 3900 rpm | 3900 rpm | – |
| Maximum working speed 400VAC (ambient temperature 0 to +40°C) | – | 5000 | – | 5000 | 5000 | 3900 |
| Torque Constant (ambient temperature 0 to +40°C) | 0.526 Nm/Arms | 0.91 Nm/Arms | 0.526 Nm/Arms | 0.91 Nm/Arms | 0.91 Nm/Arms | 1.6 Nm/Arms |
| Voltage Constant (ambient temperature 0 to +40°C) | 31.8 Vrms/Krpm | 55 Vrms/Krpm | 31.8 Vrms/Krpm | 55 Vrms/Krpm | 55 Vrms/Krpm | 96 Vrms/Krpm |
| Winding resistance (ambient temperature 0 to +40°C) | 2.3 Ω | 6.5 Ω | 0.99 Ω | 3 Ω | 1.9 Ω | 6.5 Ω |
| Winding inductance (ambient temperature 0 to +40°C) | 7.4 mH | 22.2 mH | 4.4 mH | 13.2 mH | 8.9 mH | 28.6 mH |
| Electrical time constant (ambient temperature 0 to +40°C) | 3.2 ms | 3.4 ms | 4.4 ms | 4.4 ms | 4.7 ms | 4.4 ms |
| Thermal Resistance (ambient temperature 0 to +40°C) | 1.67 °C/W | 1.67 °C/W | 1.32 °C/W | 1.32 °C/W | 1 °C/W | 1 °C/W |
| Mechanical time constant (ambient temperature 0 to +40°C) | 0.8 ms | 0.75 ms | 0.62 ms | 0.63 ms | 0.54 ms | 0.6 ms |
| Rotor Inertia without feedback (ambient temperature 0 to +40°C) | 0.64 kg·cm² | 0.64 kg·cm² | 1.16 kg·cm² | 1.16 kg·cm² | 1.58 kg·cm² | 1.58 kg·cm² |
| Mass (ambient temperature 0 to +40°C) | 2.25 Kg | 2.25 Kg | 3.05 Kg | 3.05 Kg | 4.1 Kg | 4.1 Kg |
| Maximum axial shaft load applied on the shaft’s center (ambient temperature 0 to +40°C) | 110 N | 110 N | 110 N | 110 N | 110 N | 110 N |
| Maximun radial shaft load applied on the shaft’s center (ambient temperature 0 to +40°C) | 350 N | 350 N | 350 N | 350 N | 350 N | 350 N |
| Family Specification | Produkt |
|---|---|
| Time Rating | Continous |
| Insulation Class | F |
| Enclosure | Totally enclosed. Self-cooled |
| Protection Class | IP 65 standard on the body |
| Insulation System UL/CSA | cURus , DV155J File nr. : E216686 |
| Ambient Temperature | -40 to 80 °C |
| Ambient Humidity | 5 to 85% (non-condensing) |
| Poles | 8 |
| Thermal Protection | PT1000 |
| Certification | CE |
| Family Overview | Produkt |
|---|---|
| Flange dimensions | 80 mm |
| Rated Output Power | 480 – 1068 Watt |
| Rated Torque | 1,53 – 3,4 Nm |
| Rated Speed | 3000 rpm |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
datasheet
| Specification | TC-X 80 1,5 21 |
|---|---|
| Continous Stall Torque (ambient temperature 0 to +40°C) | 1.74 Nm |
| Peak Torque (ambient temperature 0 to +40°C) | 4.5 Nm |
| Nominal Torque (ambient temperature 0 to +40°C) | 1.53 Nm |
| Rated Voltage (ambient temperature 0 to +40°C) | 230 Vdc |
| Nominal power (ambient temperature 0 to +40°C) | 480 W |
| Continuous stall Current (ambient temperature 0 to +40°C) | 3.31 Arms |
| Maximun Current (ambient temperature 0 to +40°C) | 8.55 Arms |
| Nominal Current (ambient temperature 0 to +40°C) | 2.99 Arms |
| Nominal working Speed (ambient temperature 0 to +40°C) | 3000 rpm |
| Maximum working speed 230VAC (ambient temperature 0 to +40°C) | 5000 rpm |
| Maximum working speed 400VAC (ambient temperature 0 to +40°C) | – |
| Torque Constant (ambient temperature 0 to +40°C) | 0.526 Nm/Arms |
| Voltage Constant (ambient temperature 0 to +40°C) | 31.8 Vrms/Krpm |
| Winding resistance (ambient temperature 0 to +40°C) | 2.3 Ω |
| Winding inductance (ambient temperature 0 to +40°C) | 7.4 mH |
| Electrical time constant (ambient temperature 0 to +40°C) | 3.2 ms |
| Thermal Resistance (ambient temperature 0 to +40°C) | 1.67 °C/W |
| Mechanical time constant (ambient temperature 0 to +40°C) | 0.8 ms |
| Rotor Inertia without feedback (ambient temperature 0 to +40°C) | 0.64 kg·cm² |
| Mass (ambient temperature 0 to +40°C) | 2.25 Kg |
| Maximum axial shaft load applied on the shaft’s center (ambient temperature 0 to +40°C) | 110 N |
| Maximun radial shaft load applied on the shaft’s center (ambient temperature 0 to +40°C) | 350 N |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
datasheet
| Specification | TC-X 80 1,5 15 |
|---|---|
| Continous Stall Torque (ambient temperature 0 to +40°C) | 1.74 Nm |
| Peak Torque (ambient temperature 0 to +40°C) | 4.5 Nm |
| Nominal Torque (ambient temperature 0 to +40°C) | 1.53 Nm |
| Rated Voltage (ambient temperature 0 to +40°C) | 400 Vdc |
| Nominal power (ambient temperature 0 to +40°C) | 480 W |
| Continuous stall Current (ambient temperature 0 to +40°C) | 1.91 Arms |
| Maximun Current (ambient temperature 0 to +40°C) | 4.95 Arms |
| Nominal Current (ambient temperature 0 to +40°C) | 1.73 Arms |
| Nominal working Speed (ambient temperature 0 to +40°C) | 3000 rpm |
| Maximum working speed 230VAC (ambient temperature 0 to +40°C) | 3900 rpm |
| Maximum working speed 400VAC (ambient temperature 0 to +40°C) | 5000 |
| Torque Constant (ambient temperature 0 to +40°C) | 0.91 Nm/Arms |
| Voltage Constant (ambient temperature 0 to +40°C) | 55 Vrms/Krpm |
| Winding resistance (ambient temperature 0 to +40°C) | 6.5 Ω |
| Winding inductance (ambient temperature 0 to +40°C) | 22.2 mH |
| Electrical time constant (ambient temperature 0 to +40°C) | 3.4 ms |
| Thermal Resistance (ambient temperature 0 to +40°C) | 1.67 °C/W |
| Mechanical time constant (ambient temperature 0 to +40°C) | 0.75 ms |
| Rotor Inertia without feedback (ambient temperature 0 to +40°C) | 0.64 kg·cm² |
| Mass (ambient temperature 0 to +40°C) | 2.25 Kg |
| Maximum axial shaft load applied on the shaft’s center (ambient temperature 0 to +40°C) | 110 N |
| Maximun radial shaft load applied on the shaft’s center (ambient temperature 0 to +40°C) | 350 N |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
datasheet
| Specification | TC-X 80 2,8 21 |
|---|---|
| Continous Stall Torque (ambient temperature 0 to +40°C) | 2.96 Nm |
| Peak Torque (ambient temperature 0 to +40°C) | 8.4 Nm |
| Nominal Torque (ambient temperature 0 to +40°C) | 2.55 Nm |
| Rated Voltage (ambient temperature 0 to +40°C) | 230 Vdc |
| Nominal power (ambient temperature 0 to +40°C) | 800 W |
| Continuous stall Current (ambient temperature 0 to +40°C) | 5.36 Arms |
| Maximun Current (ambient temperature 0 to +40°C) | 15.97 Arms |
| Nominal Current (ambient temperature 0 to +40°C) | 4.99 Arms |
| Nominal working Speed (ambient temperature 0 to +40°C) | 3000 rpm |
| Maximum working speed 230VAC (ambient temperature 0 to +40°C) | 5000 rpm |
| Maximum working speed 400VAC (ambient temperature 0 to +40°C) | – |
| Torque Constant (ambient temperature 0 to +40°C) | 0.526 Nm/Arms |
| Voltage Constant (ambient temperature 0 to +40°C) | 31.8 Vrms/Krpm |
| Winding resistance (ambient temperature 0 to +40°C) | 0.99 Ω |
| Winding inductance (ambient temperature 0 to +40°C) | 4.4 mH |
| Electrical time constant (ambient temperature 0 to +40°C) | 4.4 ms |
| Thermal Resistance (ambient temperature 0 to +40°C) | 1.32 °C/W |
| Mechanical time constant (ambient temperature 0 to +40°C) | 0.62 ms |
| Rotor Inertia without feedback (ambient temperature 0 to +40°C) | 1.16 kg·cm² |
| Mass (ambient temperature 0 to +40°C) | 3.05 Kg |
| Maximum axial shaft load applied on the shaft’s center (ambient temperature 0 to +40°C) | 110 N |
| Maximun radial shaft load applied on the shaft’s center (ambient temperature 0 to +40°C) | 350 N |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
datasheet
| Specification | TC-X 80 2,8 15 |
|---|---|
| Continous Stall Torque (ambient temperature 0 to +40°C) | 2.96 Nm |
| Peak Torque (ambient temperature 0 to +40°C) | 8.4 Nm |
| Nominal Torque (ambient temperature 0 to +40°C) | 2.55 Nm |
| Rated Voltage (ambient temperature 0 to +40°C) | 400 Vdc |
| Nominal power (ambient temperature 0 to +40°C) | 800 W |
| Continuous stall Current (ambient temperature 0 to +40°C) | 3.25 Arms |
| Maximun Current (ambient temperature 0 to +40°C) | 9.23 Arms |
| Nominal Current (ambient temperature 0 to +40°C) | 2.88 Arms |
| Nominal working Speed (ambient temperature 0 to +40°C) | 3000 rpm |
| Maximum working speed 230VAC (ambient temperature 0 to +40°C) | 3900 rpm |
| Maximum working speed 400VAC (ambient temperature 0 to +40°C) | 5000 |
| Torque Constant (ambient temperature 0 to +40°C) | 0.91 Nm/Arms |
| Voltage Constant (ambient temperature 0 to +40°C) | 55 Vrms/Krpm |
| Winding resistance (ambient temperature 0 to +40°C) | 3 Ω |
| Winding inductance (ambient temperature 0 to +40°C) | 13.2 mH |
| Electrical time constant (ambient temperature 0 to +40°C) | 4.4 ms |
| Thermal Resistance (ambient temperature 0 to +40°C) | 1.32 °C/W |
| Mechanical time constant (ambient temperature 0 to +40°C) | 0.63 ms |
| Rotor Inertia without feedback (ambient temperature 0 to +40°C) | 1.16 kg·cm² |
| Mass (ambient temperature 0 to +40°C) | 3.05 Kg |
| Maximum axial shaft load applied on the shaft’s center (ambient temperature 0 to +40°C) | 110 N |
| Maximun radial shaft load applied on the shaft’s center (ambient temperature 0 to +40°C) | 350 N |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
datasheet
| Specification | TC-X 80 4 15 |
|---|---|
| Continous Stall Torque (ambient temperature 0 to +40°C) | 4 Nm |
| Peak Torque (ambient temperature 0 to +40°C) | 12 Nm |
| Nominal Torque (ambient temperature 0 to +40°C) | 3.4 Nm |
| Rated Voltage (ambient temperature 0 to +40°C) | 230 Vdc |
| Nominal power (ambient temperature 0 to +40°C) | 1068 W |
| Continuous stall Current (ambient temperature 0 to +40°C) | 4.4 Arms |
| Maximun Current (ambient temperature 0 to +40°C) | 13.19 Arms |
| Nominal Current (ambient temperature 0 to +40°C) | 3.85 Arms |
| Nominal working Speed (ambient temperature 0 to +40°C) | 3000 rpm |
| Maximum working speed 230VAC (ambient temperature 0 to +40°C) | 3900 rpm |
| Maximum working speed 400VAC (ambient temperature 0 to +40°C) | 5000 |
| Torque Constant (ambient temperature 0 to +40°C) | 0.91 Nm/Arms |
| Voltage Constant (ambient temperature 0 to +40°C) | 55 Vrms/Krpm |
| Winding resistance (ambient temperature 0 to +40°C) | 1.9 Ω |
| Winding inductance (ambient temperature 0 to +40°C) | 8.9 mH |
| Electrical time constant (ambient temperature 0 to +40°C) | 4.7 ms |
| Thermal Resistance (ambient temperature 0 to +40°C) | 1 °C/W |
| Mechanical time constant (ambient temperature 0 to +40°C) | 0.54 ms |
| Rotor Inertia without feedback (ambient temperature 0 to +40°C) | 1.58 kg·cm² |
| Mass (ambient temperature 0 to +40°C) | 4.1 Kg |
| Maximum axial shaft load applied on the shaft’s center (ambient temperature 0 to +40°C) | 110 N |
| Maximun radial shaft load applied on the shaft’s center (ambient temperature 0 to +40°C) | 350 N |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
datasheet
| Specification | TC-X 80 4 17 |
|---|---|
| Continous Stall Torque (ambient temperature 0 to +40°C) | 4 Nm |
| Peak Torque (ambient temperature 0 to +40°C) | 12 Nm |
| Nominal Torque (ambient temperature 0 to +40°C) | 3.4 Nm |
| Rated Voltage (ambient temperature 0 to +40°C) | 400 Vdc |
| Nominal power (ambient temperature 0 to +40°C) | 1068 W |
| Continuous stall Current (ambient temperature 0 to +40°C) | 2.5 Arms |
| Maximun Current (ambient temperature 0 to +40°C) | 7.5 Arms |
| Nominal Current (ambient temperature 0 to +40°C) | 2.19 Arms |
| Nominal working Speed (ambient temperature 0 to +40°C) | 3000 rpm |
| Maximum working speed 230VAC (ambient temperature 0 to +40°C) | – |
| Maximum working speed 400VAC (ambient temperature 0 to +40°C) | 3900 |
| Torque Constant (ambient temperature 0 to +40°C) | 1.6 Nm/Arms |
| Voltage Constant (ambient temperature 0 to +40°C) | 96 Vrms/Krpm |
| Winding resistance (ambient temperature 0 to +40°C) | 6.5 Ω |
| Winding inductance (ambient temperature 0 to +40°C) | 28.6 mH |
| Electrical time constant (ambient temperature 0 to +40°C) | 4.4 ms |
| Thermal Resistance (ambient temperature 0 to +40°C) | 1 °C/W |
| Mechanical time constant (ambient temperature 0 to +40°C) | 0.6 ms |
| Rotor Inertia without feedback (ambient temperature 0 to +40°C) | 1.58 kg·cm² |
| Mass (ambient temperature 0 to +40°C) | 4.1 Kg |
| Maximum axial shaft load applied on the shaft’s center (ambient temperature 0 to +40°C) | 110 N |
| Maximun radial shaft load applied on the shaft’s center (ambient temperature 0 to +40°C) | 350 N |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
