Flange dimensions: 80 mm
Rated Output Power: 480 W
Rated Torque: 1,53 – 1,54 Nm
Rated Speed: 3000 rpm
| Specification | TC-L 80 1,5 01 | TC-L 80 1,5 03 | TC-L 80 2,8 02 |
|---|---|---|---|
| Stall Torque | 1.74 Nm | 1.74 Nm | – |
| Stall Torque for S1 | – | – | 2 Nm |
| Stall Torque for S2 for intermittent duty S2 T= 10’/20′ | – | – | 2.8 Nm |
| Peak Torque | 4.5 Nm | 4.5 Nm | 8.4 Nm |
| Rated Torque | 1.53 Nm | 1.53 Nm | – |
| Rated Torque S1 | – | – | 1.54 Nm |
| Rated Torque for S2 for intermittent duty S2 T= 10’/20′ | – | – | 2.34 Nm |
| Rated Voltage | 48 Vdc | 48 Vdc | 48 Vdc |
| Rated Output Power | 480 W | 480 W | – |
| Rated Output Power for S1 | – | – | 480 W |
| Rated Output Power for S2 for intermittent duty S2 T= 10’/20′ | – | – | 735 W |
| Stall Current | 18.5 Arms | 12.3 Arms | – |
| Stall Current for S1 | – | – | 17.7 Arms |
| Stall Current for S2 for intermittent duty S2 T= 10’/20′ | – | – | 24.8 Arms |
| Peak Current | 52.7 Arms | 35.1 Arms | 82 Arms |
| Rated Current | 16.3 Arms | 11 Arms | – |
| Rated Current for S1 | – | – | 14.3 |
| Rated Current for S2 for intermittent duty S2 T= 10’/20′ | – | – | 21.7 |
| Rated Speed | 3000 rpm | 3000 rpm | 3000 rpm |
| Maximum Speed @48Vdc | 5000 rpm | 3700 rpm | 4700 rpm |
| Torque Constant (± 5%) | 0.094 Nm/Arms | 0.141 Nm/Arms | 0.113 Nm/Arms |
| Voltage Constant (± 5%) | 5.7 Vrms/Krpm | 8.5 Vrms/Krpm | 6.8 Vrms/Krpm |
| Phase/phase resistance (± 10%@25°C) | 0.075 Ω | 0.136 Ω | 0.064 Ω |
| Phase/phase inductance (± 10%) | 0.314 mH | 0.53 mH | 0.24 mH |
| Electrical time constant | 4.2 ms | 3.9 ms | 3.75 ms |
| Thermal Resistance | 1.67 °C/W | 1.67 °C/W | 2.13 °C/W |
| Mechanical time constant | 0.8 ms | 0.8 ms | 0.65 ms |
| Rotor Inertia without brake and without feedback | 0.64 kg·cm² | 0.64 kg·cm² | 1.16 kg·cm² |
| Motor weight | 2.25 Kg | 2.25 Kg | 3.05 Kg |
| Motor weight + Brake | 2.97 Kg | 2.97 Kg | 3.77 Kg |
| Axial Load applied on the shaft’s center | 110 N | 110 N | 110 N |
| Radial Load applied on the shaft’s center | 350 N | 350 N | 350 N |
| Family Specification | Produkt |
|---|---|
| Time Rating | Continuous |
| Insulation Class | F |
| Enclosure | Totally enclosed. Self-cooled |
| Protection Class | IP 65 standard on the body |
| Motor Insulation System UL/CSA | cURus , DV155J File nr. : E216686 |
| Ambient Temperature | 0 to 40 °C |
| Ambient Humidity | 20 to 80% (non-condensing) % |
| Poles | 8 |
| Thermal Protection | PT 1000 |
| Certification | CE |
| Recommendation | Rated output with 250 x 250 x 6 mm metallic heat sink flange coupling – Derating must be considered if the oil seal is applied – IP 54 standard shaft bushing |
| Family Overview | Produkt |
|---|---|
| Flange dimensions | 80 mm |
| Rated Output Power | 480 Watt |
| Rated Torque | 1,53 – 1,54 Nm |
| Rated Speed | 3000 rpm |
