Characteristics
| Parameter | Unit | BO1613N2B01-158-3.0 | BO1613N2B02-158-6.0 | BO1613N2B03-158-9.0 |
|---|---|---|---|---|
| Voltage | V | 3.0 | 6.0 | 9.0 |
| Terminal resistance | Ohm | 0.18 | 0.82 | 1.69 |
| No-load speed | rpm | 15800 | 15800 | 15800 |
| No-load current | A | 0.29 | 0.20 | 0.10 |
| Stall torque | mNm | 29 | 26 | 28 |
| Stall current | A | 16.6 | 7.3 | 5.3 |
| Nominal torque | mNm | 7.9 | 12.1 | 11.5 |
| Nominal speed | rpm | 4250 | 4980 | 6540 |
| Nominal current | A | 4.2 | 2.6 | 1.8 |
| Max. output power | W | 12 | 11 | 11 |
| Max. efficiency | % | 75.2 | 73.8 | 74.7 |
| Back-EMF constant | mV/rpm | 0.2 | 0.4 | 0.6 |
| Torque constant | mNm/A | 1.8 | 3.6 | 5.3 |
| KV Value | rpm/V | 5290 | 2628 | 1758 |
| Speed/torque gradient | rpm/mNm | 549.5 | 617.4 | 567.9 |
| Rotor inertia | gcm² | 1.7 | 1.7 | 1.7 |
| Weight | g | 7.8 | 7.8 | 7.8 |
| Thermal resistance housing-ambient | K/W | 7.9 | 7.9 | 7.9 |
| Thermal resistance winding-housing | K/W | 6.4 | 6.4 | 6.4 |
| Thermal time constant motor | s | 123 | 123 | 123 |
| Thermal time constant winding | s | 100 | 100 | 100 |
| Operating temperature range | °C | -40~+120 | -40~+120 | -40~+120 |
| Thermal class of winding | °C | 155 | 155 | 155 |
| Axial play | mm | 0.012 | 0.012 | 0.012 |
| Radial play | mm | 0.008 | 0.008 | 0.008 |
| Axial load dynamic | N | 1 | 1 | 1 |
| Axial load static | N | 25 | 25 | 25 |
| Radial load at 3 mm from mounting face | N | 6.3 | 6.3 | 6.3 |
| No. of pole pairs | 5 | 5 | 5 | |
| Bearings | 2 ball bearings | 2 ball bearings | 2 ball bearings | |
| Protection class | IP | 20 | 20 | 20 |
| Commutation | Sensorless | Sensorless | Sensorless |
Applications
UAV
aeromodelling
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
BO1613N2B
| Parameter | Unit | BO1613N2B01-158-3.0 |
|---|---|---|
| Voltage | V | 3.0 |
| Terminal resistance | Ohm | 0.18 |
| No-load speed | rpm | 15800 |
| No-load current | A | 0.29 |
| Stall torque | mNm | 29 |
| Stall current | A | 16.6 |
| Nominal torque | mNm | 7.9 |
| Nominal speed | rpm | 4250 |
| Nominal current | A | 4.2 |
| Max. output power | W | 12 |
| Max. efficiency | % | 75.2 |
| Back-EMF constant | mV/rpm | 0.2 |
| Torque constant | mNm/A | 1.8 |
| KV Value | rpm/V | 5290 |
| Speed/torque gradient | rpm/mNm | 549.5 |
| Rotor inertia | gcm² | 1.7 |
| Weight | g | 7.8 |
| Thermal resistance housing-ambient | K/W | 7.9 |
| Thermal resistance winding-housing | K/W | 6.4 |
| Thermal time constant motor | s | 123 |
| Thermal time constant winding | s | 100 |
| Operating temperature range | °C | -40~+120 |
| Thermal class of winding | °C | 155 |
| Axial play | mm | 0.012 |
| Radial play | mm | 0.008 |
| Axial load dynamic | N | 1 |
| Axial load static | N | 25 |
| Radial load at 3 mm from mounting face | N | 6.3 |
| No. of pole pairs | 5 | |
| Bearings | 2 ball bearings | |
| Protection class | IP | 20 |
| Commutation | Sensorless |
Applications
UAV
aeromodelling
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Parameter | Unit | BO1613N2B02-158-6.0 |
|---|---|---|
| Voltage | V | 6.0 |
| Terminal resistance | Ohm | 0.82 |
| No-load speed | rpm | 15800 |
| No-load current | A | 0.20 |
| Stall torque | mNm | 26 |
| Stall current | A | 7.3 |
| Nominal torque | mNm | 12.1 |
| Nominal speed | rpm | 4980 |
| Nominal current | A | 2.6 |
| Max. output power | W | 11 |
| Max. efficiency | % | 73.8 |
| Back-EMF constant | mV/rpm | 0.4 |
| Torque constant | mNm/A | 3.6 |
| KV Value | rpm/V | 2628 |
| Speed/torque gradient | rpm/mNm | 617.4 |
| Rotor inertia | gcm² | 1.7 |
| Weight | g | 7.8 |
| Thermal resistance housing-ambient | K/W | 7.9 |
| Thermal resistance winding-housing | K/W | 6.4 |
| Thermal time constant motor | s | 123 |
| Thermal time constant winding | s | 100 |
| Operating temperature range | °C | -40~+120 |
| Thermal class of winding | °C | 155 |
| Axial play | mm | 0.012 |
| Radial play | mm | 0.008 |
| Axial load dynamic | N | 1 |
| Axial load static | N | 25 |
| Radial load at 3 mm from mounting face | N | 6.3 |
| No. of pole pairs | 5 | |
| Bearings | 2 ball bearings | |
| Protection class | IP | 20 |
| Commutation | Sensorless |
Applications
UAV
aeromodelling
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
BO1613N2B
| Parameter | Unit | BO1613N2B03-158-9.0 |
|---|---|---|
| Voltage | V | 9.0 |
| Terminal resistance | Ohm | 1.69 |
| No-load speed | rpm | 15800 |
| No-load current | A | 0.10 |
| Stall torque | mNm | 28 |
| Stall current | A | 5.3 |
| Nominal torque | mNm | 11.5 |
| Nominal speed | rpm | 6540 |
| Nominal current | A | 1.8 |
| Max. output power | W | 11 |
| Max. efficiency | % | 74.7 |
| Back-EMF constant | mV/rpm | 0.6 |
| Torque constant | mNm/A | 5.3 |
| KV Value | rpm/V | 1758 |
| Speed/torque gradient | rpm/mNm | 567.9 |
| Rotor inertia | gcm² | 1.7 |
| Weight | g | 7.8 |
| Thermal resistance housing-ambient | K/W | 7.9 |
| Thermal resistance winding-housing | K/W | 6.4 |
| Thermal time constant motor | s | 123 |
| Thermal time constant winding | s | 100 |
| Operating temperature range | °C | -40~+120 |
| Thermal class of winding | °C | 155 |
| Axial play | mm | 0.012 |
| Radial play | mm | 0.008 |
| Axial load dynamic | N | 1 |
| Axial load static | N | 25 |
| Radial load at 3 mm from mounting face | N | 6.3 |
| No. of pole pairs | 5 | |
| Bearings | 2 ball bearings | |
| Protection class | IP | 20 |
| Commutation | Sensorless |
Applications
UAV
aeromodelling
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
