MFM1 MicroDrive with
MForce MicroDrive Step/direction Input with isolated +5 to +24 V universal inputs cis a high performance, high resolution microstepping driver. High +12 to +48 VDC input voltage and an output current of 3.0 A RMS (4.0 A Peak). Parameters are set over SPI using an included utility .
| Specification | MFM1 MicroDrive Step/direction Input |
|---|---|
| Control type | Step/Direction |
| Control interface | Step, direction and enable inputs |
| Driver type | Microstepping |
| Operating temperature | 2 °C |
| Input voltage | +12 to +48 +VDC |
| Output voltage | 3.0 A |
| Motion step frequency | 2.5 MHz max |
| Motion step resolutions | 1 … 256 steps/full step |
