Description
Planetary Gearbox Series
| Parameter | Unit | L0615-1300-3.0-06PF25-0025 |
|---|---|---|
| Voltage | V | 3.0 |
| Terminal resistance | Ω | 13.7 |
| No-load speed | rpm | 1300 |
| No-load current | mA | 50 |
| Max torque | mNm | 2.94 |
| Load torque | mNm | 0.2 |
| Load speed | rpm | 1200 |
| Load current | mA | 60 |
| Reduction ratio | 1/25 | |
| Weight | g | 1.2 |
| Operating temperature range | °C | -10～+70 |
Applications
medical equipment
security systems and locks
audio and visual products
personal healthcare products
high-end hobby products
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
