Description
17mm BLDC outer rotor, sensorless
17mm BLDC outer rotor, sensorless
Specification | BO1709NB2B01-260-10.0 |
---|---|
Voltage | 10.0 V |
Terminal resistance | 4.3 Ω |
Terminal inductance | 0.46 mH |
No-load speed | 26000 rpm |
No-load current | 0.12 A |
Stall torque | 7.7 mNm |
Stall current | 2.3 A |
Nominal torque | 1.9 mNm |
Nominal speed | 16380 rpm |
Nominal current | 0.7 A |
Max. output power | 5.2 W |
Max. efficiency | 60 % |
Back-EMF constant | 0.4 mV/rpm |
Torque constant | 3.5 mNm/A |
Speed/torque gradient | 3384 rpm/mNm |
Rotor inertia | 1.2 gcm² |
Weight | 7.5 g |
Thermal resistance housing-ambient | 15.4 K/W |
Thermal resistance winding-housing | 13.6 K/W |
Thermal time constant motor | 128 s |
Thermal time constant winding | 43 s |
Operating temperature range | -40~+120 °C |
Thermal class of winding | 155 °C |
Axial play | 0.012 mm |
Radial play | 0.008 mm |
Axial load dynamic | 1.5 N |
Axial load static | 37 N |
Radial load at 3 mm from mounting face | 12 N |
No. of pole pairs | 4 |
Bearings | 2 ball bearings |
Protection class | 30 IP |
Commutation | Sensorless |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
