| Specification | 28ZWC58L-1 |
|---|---|
| Pole pair | 2 |
| Winding connection method | Star shape |
| Phase resistance | 0.676 Ω |
| Phase inductance | 0.2 mH |
| Insulation class | B |
| Duty type | S2 |
| Feedback method | Hall Sensors |
| Commutation angle | 120° |
| Insulation strength (Withstand voltage) | 500VAC/1KHz/1mA/1s |
| Insulation resistance | 100 MΩ/500VDC |
| Weight | 300 g |
| Rated voltage | 24 V |
| Rated power | 52.4 W |
| Rated torque | 0.05 Nm |
| Rated speed | 10000 RPM |
| Rated current | 3 A |
| No load speed | 12000 RPM |
| No load current | 0.5 A |
| Motor efficiency | 77 % |
| Static torque | 12.8 mNm |
| Noise (Ambient noise 20db, test distance 1M) | ＜50 dB |
| Enclosure – Ambient Thermal Resistance | 0.38 K/W |
| Ambient temperature | 25 °C |
| Maximum winding temperature | 75 °C |
| Torque constant | 0.017 N·m/A |
| Back-EMF Constant /Effective Value | 1.78 V/Krpm |
| Peak torque | 0.15 Nm |
| Peak current | 9 A |
| Inertia Moment | 0.011 kg·cm² |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
