Description
KOCO MOTION’s ower-off Brakes are engineered for dependable static holding and emergency braking in industrial automation, robotics, and vertical drive applications. Designed for NEMA 8, 11, 14, 17, 23, 24, and 34 motor sizes, these 24VDC magnetic brakes activate to hold position or stop loads securely during power loss or system emergencies, minimizing uncontrolled movement and safety risks.
- Wide Motor Compatibility: Suitable for a broad range of NEMA frame sizes with models delivering hold torques from 0.06Nm to 5.0Nm.
- High Reliability: Rated for up to 500,000 cycles (standard) and designed for low noise operation (<60dB), reducing maintenance needs and workplace disturbance.
- Electrical Performance: Operates at 24VDC ±5% with industry-standard insulation class B, dielectric strength of 1000VAC (1s), and insulation resistance >100MΩ @ 500VDC.
- Quick Response: Fast retraction and release times (as low as 30-50ms), critical for dynamic automation and safety shutdowns.
Applied in vertical axes of pick-and-place systems, conveyor brakes, servomotor safety circuits, and precision machinery, DINGS brakes offer assured load retention and consistent stopping power. With robust design, easy motor integration, long service life, and low acoustic output, they help industrial engineers and OEMs enhance both safety and productivity in mission-critical projects.
