MDM1 NEMA 17 Step/direction Input IP20

Name: MDM1 NEMA 17 Step/direction Input IP20 - KOCO MOTION
SKU: MDM1 NEMA 17 Step/direction Input IP20

Loggen Sie sich ein, um Preise für dieses Produkt zu sehen

inkl. 19 % MwSt.

MDM1 NEMA 17 with

Pulse/Direction(SPI)

Artikelnummer: MDM1 NEMA 17 Step/direction Input IP20 Kategorie: Liberty/MDrives

Beschreibung

Beschreibung

MDrive Plus NEMA size 17 (42 mm) Step/direction input with SPI interface for parameterization.
This product features 24 VDC optically isolated step and direction inputs.
Holding torque range oz-in (N-cm): 23 … 53 (23 … 53)
I/O connector options: Flying Leads, Pluggable, Wire Crimp
Com connector: None

Specification	MDM1 NEMA 17 Step/direction Input IP20
Control type	Step/direction input
Feature set	Clock and direction inputs
P1 connector options	Flying Leads, Pluggable, Wire Crimp Power & I/O
P2 connector options	None Comm
Communications interface	SPI
Communications features	–
NEMA size	17 (42×42 mm)
Holding torque range	0.23 … 0.53 Nm
Temperature heatsink (short-time)	max. 85 °C
IP rating	IP20
Input voltage	+12 to +48 +VDC
Power supply current requirement	2.0 A

Parameter settings	MDM1 NEMA 17 Step/direction Input IP20
Input Step, Direction & Enable voltage	5 … 24 + VDC
Current	14.6 mA Max
Digital Filter Range	10 … 38.8 MHz … kHz
Step Frequency	5 MHz Max
Microstep Resolutions	200 … 51200 Steps/Rev
Clock Types	–

Name	Unit	Single Length	Triple Length
Holding torque	Ncm	13	25
Rotor inertia	kgcm2	0.014	0.0566
Detent Torque	Ncm	1.4	3.1
Weight	g	150	380
