Outer Rotor

The Outer Rotors are high-pole brushless motors that have high torque and high power density.

16 Produkte entsprechen den Kriterien

Sortierung:

|

Ansicht:

7054ZWF-2ZP-250A-24.0

7054ZWF-2ZP-250A-24.0

Terminal resistance 2.0Ω

Input power 20W

Rated Load Blades, blow hole: 4mm

BF3211NB2B02-145-12.0

BF3211NB2B02-145-12.0

Terminal resistance 4.2Ω

Terminal inductance 0.27mH

No-load speed 14500rpm

No-load current 0.1A

BO1012N2B02-330-4.5

BO1012N2B02-330-4.5

Terminal resistance 0.65Ω

No-load speed 33300rpm

No-load current 0.35A

Stall torque 8.0mNm

BO1410NB2B02-81-6.0

BO1410NB2B02-81-6.0

Terminal resistance 13.4Ω

Terminal inductance 0.74mH

No-load speed 8100rpm

No-load current 0.04A

BO1509NBH2B01-280-7.6

BO1509NBH2B01-280-7.6

Terminal resistance 4.0Ω

Terminal inductance 0.21mH

No-load speed 28000A

No-load current 0.10mA

BO1808NBH2B01-140-11.4

BO1808NBH2B01-140-11.4

Terminal resistance 14.5Ω

Terminal inductance 0.8mH

No-load speed 14300rpm

No-load current 0.12A

BO2008NBH2B01-73-11.4

BO2008NBH2B01-73-11.4

Terminal resistance 26.0Ω

Terminal inductance 2.30mH

No-load speed 7200rpm

No-load current 0.05A

BO43**---42MP---

BO43**—42MP—BO4326NBH2B01-92-48.0

Terminal resistance 1.0Ω

No-load speed 9200rpm

No-load current 0.3mA

Stall torque 2361mNm

BO43**---42MP---

BO43**—42MP—BO4326NBH2B02-92-36.0

Terminal resistance 0.45Ω

No-load speed 9200rpm

No-load current 0.5mA

Stall torque 2952mNm

BO43**---42MP---

BO43**—42MP—BO4326NBH2B03-92-24.0

Terminal resistance 0.21Ω

No-load speed 9200rpm

No-load current 0.6mA

Stall torque 2817mNm
