Flange dimensions: 80 mm
Rated Output Power: 480 – 1068 W
Rated Torque: 1,53 – 3,4 Nm
Rated Speed: 3000 rpm
| Specification | TC 80 1,5 21 | TC 80 1,5 15 | TC 80 2,8 21 | TC 80 2,8 15 | TC 80 4 15 | TC 80 4 17 |
|---|---|---|---|---|---|---|
| Continous Stall Torque | 1.74 Nm | 1.74 Nm | 2.96 Nm | 2.96 Nm | 4 Nm | 4 Nm |
| Peak Torque | 4.5 Nm | 4.5 Nm | 8.4 Nm | 8.4 Nm | 12 Nm | 12 Nm |
| Nominal Torque | 1.53 Nm | 1.53 Nm | 2.55 Nm | 2.55 Nm | 3.4 Nm | 3.4 Nm |
| Rated Voltage | 230 V | 400 V | 230 V | 400 V | 230 V | 400 V |
| Nominal power | 480 W | 480 W | 800 W | 800 W | 1068 W | 1068 W |
| Continuous stall Current | 3.31 Arms | 1.91 Arms | 5.63 Arms | 3.25 Arms | 4.4 Arms | 2.5 Arms |
| Maximun Current | 8.55 Arms | 4.95 Arms | 15.97 Arms | 9.23 Arms | 13.19 Arms | 7.5 Arms |
| Nominal Current | 2.99 Arms | 1.73 Arms | 4.99 Arms | 2.88 Arms | 3.85 Arms | 2.19 Arms |
| Nominal working Speed | 3000 rpm | 3000 rpm | 3000 rpm | 3000 rpm | 3000 rpm | 3000 rpm |
| Maximum working speed 230VAC | 5000 rpm | 3900 rpm | 5000 rpm | 3900 rpm | 3900 rpm | – |
| Maximum working speed 400VAC | – | 5000 | – | 5000 | 5000 | 5000 |
| Torque Constant | 0.526 Nm/Arms | 0.91 Nm/Arms | 0.526 Nm/Arms | 0.91 Nm/Arms | 0.91 Nm/Arms | 1.6 Nm/Arms |
| Voltage Constant | 31.8 Vrms/Krpm | 55 Vrms/Krpm | 31.8 Vrms/Krpm | 55 Vrms/Krpm | 55 Vrms/Krpm | 96 Vrms/Krpm |
| Winding resistance | 2.3 Ω | 6.5 Ω | 0.99 Ω | 3 Ω | 1.9 Ω | 6.5 Ω |
| Winding inductance | 7.4 mH | 22.2 mH | 4.4 mH | 13.2 mH | 8.9 mH | 28.6 mH |
| Electrical time constant | 3.2 ms | 3.4 ms | 4.4 ms | 4.4 ms | 4.7 ms | 4.4 ms |
| Thermal Resistance | 1.67 °C/W | 1.67 °C/W | 1.32 °C/W | 1.32 °C/W | 1 °C/W | 1 °C/W |
| Mechanical time constant | 0.8 ms | 0.75 ms | 0.62 ms | 0.63 ms | 0.54 ms | 0.6 ms |
| Rotor Inertia without brake and without feedback | 0.64 kg·cm² | 0.64 kg·cm² | 1.16 kg·cm² | 1.16 kg·cm² | 1.58 kg·cm² | 1.58 kg·cm² |
| Mass without holding brake | 2.25 Kg | 2.25 Kg | 3.05 Kg | 3.05 Kg | 4.1 Kg | 4.1 Kg |
| Mass with holding brake | 2.97 Kg | 2.97 Kg | 3.77 Kg | 3.77 Kg | 4.82 Kg | 4.82 Kg |
| Maximum axial shaft load applied on the shaft’s center | 110 N | 110 N | 110 N | 110 N | 110 N | 110 N |
| Maximun radial shaft load applied on the shaft’s center | 350 N | 350 N | 350 N | 350 N | 350 N | 350 N |
| Family Specification | Produkt |
|---|---|
| Time Rating | Continuous |
| Insulation Class | F |
| Enclosure | Totally enclosed. Self-cooled |
| Protection Class | IP 65 standard on the body |
| Insulation System UL/CSA | cURus , DV155J File nr. : E216686 |
| Ambient Temperature | 0 to 40 °C |
| Ambient Humidity | 5 to 85% (non-condensing) % |
| Poles | 8 |
| Thermal Protection | PT 1000 |
| Certification | CE |
| Recommendation | Rated output with 250 x 250 x 6 mm metallic heat sink flange coupling – Derating must be considered if the oil seal is applied – IP 54 standard shaft bushing |
| Family Overview | Produkt |
|---|---|
| Flange dimensions | 80 mm |
| Rated Output Power | 480 – 1068 Watt |
| Rated Torque | 1,53 – 3,4 Nm |
| Rated Speed | 3000 rpm |
