| Characteristics | VL0615N5M47-100-3.0 | VL0615N5M02-92-1.5 |
|---|---|---|
| Voltage | 3.0 V | 1.5 V |
| Terminal resistance | 20 Ω | 6.9 Ω |
| Speed | 10000 rpm | 9200 rpm |
| Current | 45 mA | 100 mA |
| Starting voltage | 0.6 V | 0.8 V |
| Stall current | 150 mA | 220 mA |
| Weight | 3.4 g | 2.8 g |
| Operating temperature range | -10～+65 | -10～+65 |
Applications
wearable products
mobile phones
tablet PC´s
health care products
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | VL0615N5M47-100-3.0 |
|---|---|
| Voltage | 3.0 V |
| Terminal resistance | 20 Ω |
| Speed | 10000 rpm |
| Current | 45 mA |
| Starting voltage | 0.6 V |
| Stall current | 150 mA |
| Weight | 3.4 g |
| Operating temperature range | -10～+65 °C |
Applications
wearable products
mobile phones
tablet PC´s
health care products
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | VL0615N5M02-92-1.5 |
|---|---|
| Voltage | 1.5 V |
| Terminal resistance | 6.9 Ω |
| Speed | 9200 rpm |
| Current | 100 mA |
| Starting voltage | 0.8 V |
| Stall current | 220 mA |
| Weight | 2.8 g |
| Operating temperature range | -10～+65 °C |
Applications
wearable products
mobile phones
tablet PC´s
health care products
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
