| Specification | L1620N5M33-85-5.0 | L1620N5M20-95-5.0 | L1620N5M29-80-5.0 |
|---|---|---|---|
| Voltage | 5.0 V | 5.0 V | 5.0 V |
| Terminal resistance | 3.9 Ω | 4.1 Ω | 3.7 Ω |
| No-load speed | 8550 rpm | 9500 rpm | 8000 rpm |
| No-load current | 35 mA | 35 mA | 25 mA |
| Stall torque | 6.8 mNm | 5.78 mNm | 7.8 mNm |
| Stall current | 1280 mA | 1220 mA | 1350 mA |
| Load torque | 1.0 mNm | 1.0 mNm | 1.0 mNm |
| Load speed | 7290 rpm | 7860 rpm | 6970 rpm |
| Load current | 220 mA | 240 mA | 200 mA |
| Max. output power | 1.5 W | 1.4 W | 1.6 W |
| Max. efficiency | 70 % | 69 % | 75 % |
| Back-EMF constant | 0.6 mV/rpm | 0.5 mV/rpm | 0.6 mV/rpm |
| Torque constant | 5.4 mNm/A | 4.9 mNm/A | 5.9 mNm/A |
| Speed/torque gradient | 1260 rpm/mNm | 1640 rpm/mNm | 1030 rpm/mNm |
| Rotor inertia | 0.45 g·cm² | 0.45 g·cm² | 0.45 g·cm² |
| Weight | 15.8 g | 15.8 g | 15.8 g |
| Operating temperature range | -20~+85 | -20~+85 | -20~+85 |
Applications
mini UAV
remote control hobby products
small household appliances
L1620N5M
| Specification | L1620N5M33-85-5.0 |
|---|---|
| Voltage | 5.0 V |
| Terminal resistance | 3.9 Ω |
| No-load speed | 8550 rpm |
| No-load current | 35 mA |
| Stall torque | 6.8 mNm |
| Stall current | 1280 mA |
| Load torque | 1.0 mNm |
| Load speed | 7290 rpm |
| Load current | 220 mA |
| Max. output power | 1.5 W |
| Max. efficiency | 70 % |
| Back-EMF constant | 0.6 mV/rpm |
| Torque constant | 5.4 mNm/A |
| Speed/torque gradient | 1260 rpm/mNm |
| Rotor inertia | 0.45 g·cm² |
| Weight | 15.8 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
L1620N5M
| Specification | L1620N5M20-95-5.0 |
|---|---|
| Voltage | 5.0 V |
| Terminal resistance | 4.1 Ω |
| No-load speed | 9500 rpm |
| No-load current | 35 mA |
| Stall torque | 5.78 mNm |
| Stall current | 1220 mA |
| Load torque | 1.0 mNm |
| Load speed | 7860 rpm |
| Load current | 240 mA |
| Max. output power | 1.4 W |
| Max. efficiency | 69 % |
| Back-EMF constant | 0.5 mV/rpm |
| Torque constant | 4.9 mNm/A |
| Speed/torque gradient | 1640 rpm/mNm |
| Rotor inertia | 0.45 g·cm² |
| Weight | 15.8 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
L1620N5M
| Specification | L1620N5M29-80-5.0 |
|---|---|
| Voltage | 5.0 V |
| Terminal resistance | 3.7 Ω |
| No-load speed | 8000 rpm |
| No-load current | 25 mA |
| Stall torque | 7.8 mNm |
| Stall current | 1350 mA |
| Load torque | 1.0 mNm |
| Load speed | 6970 rpm |
| Load current | 200 mA |
| Max. output power | 1.6 W |
| Max. efficiency | 75 % |
| Back-EMF constant | 0.6 mV/rpm |
| Torque constant | 5.9 mNm/A |
| Speed/torque gradient | 1030 rpm/mNm |
| Rotor inertia | 0.45 g·cm² |
| Weight | 15.8 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
