Description
Precious Metal Commutation
| Specification | C1212FF33-0519 |
|---|---|
| Voltage | 3.0 V |
| Terminal resistance | 9.9 Ω |
| No-load speed | 13400 rpm |
| No-load current | 40 mA |
| Stall torque | 0.48 mNm |
| Stall current | 290 mA |
| Load torque | 0.156 mNm |
| Load speed | 9000 rpm |
| Load current | 122 mA |
| Max. output power | 0.17 W |
| Max. efficiency | 40.8 % |
| Back-EMF constant | 0.19 mV/rpm |
| Torque constant | – |
| Speed/torque gradient | 28205 rpm/mNm |
| Varistor | Yes Yes/No |
| Weight | 5.4 g |
| Operating temperature range | -20~+80 °C |
Applications
security equipment
small electronic products
remote control model aircraft
personal care products
portable electric tools
