| Characteristics | L0614N5M44-125-3.0 | L0614N5M28-420-3.4 | L0614N5M67-500-3.2 |
|---|---|---|---|
| Voltage | 3.0 V | 3.4 V | 3.2 V |
| Terminal resistance | 23.1 Ω | 2.60 Ω | 1.70 Ω |
| No-load speed | 12540 rpm | 42000 rpm | 50000 rpm |
| No-load current | 7.4 mA | 60 mA | 80 mA |
| Stall torque | 0.26 mNm | 0.9 mNm | 1.1 mNm |
| Stall current | 130 mA | 1308 mA | 1882 mA |
| Load torque | 0.05 mNm | 0.1 mNm | 0.1 mNm |
| Load speed | 10170 rpm | 37430 rpm | 45260 rpm |
| Load current | 30 mA | 200 mA | 250 mA |
| Max. output power | 0.09 W | 1.0 W | 1.4 W |
| Max. efficiency | 58.1 % | 61.8 % | 63.1 % |
| Back-EMF constant | 0.23 mV/rpm | 0.08 mV/rpm | 0.06 mV/rpm |
| Torque constant | 2.15 mNm/A | 0.74 mNm/A | 0.59 mNm/A |
| Speed/torque gradient | 47500 rpm/mNm | 45652 rpm/mNm | 47393 rpm/mNm |
| Rotor inertia | 0.016 g·cm² | 0.016 g·cm² | 0.016 g·cm² |
| Weight | 1.7 g | 1.7 g | 1.7 g |
| Operating temperature range | -20~+65 | -20~+80 | -20~+120 |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L0614N5M44-125-3.0 |
|---|---|
| Voltage | 3.0 V |
| Terminal resistance | 23.1 Ω |
| No-load speed | 12540 rpm |
| No-load current | 7.4 mA |
| Stall torque | 0.26 mNm |
| Stall current | 130 mA |
| Load torque | 0.05 mNm |
| Load speed | 10170 rpm |
| Load current | 30 mA |
| Max. output power | 0.09 W |
| Max. efficiency | 58.1 % |
| Back-EMF constant | 0.23 mV/rpm |
| Torque constant | 2.15 mNm/A |
| Speed/torque gradient | 47500 rpm/mNm |
| Rotor inertia | 0.016 g·cm² |
| Weight | 1.7 g |
| Operating temperature range | -20~+65 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L0614N5M28-420-3.4 |
|---|---|
| Voltage | 3.4 V |
| Terminal resistance | 2.60 Ω |
| No-load speed | 42000 rpm |
| No-load current | 60 mA |
| Stall torque | 0.9 mNm |
| Stall current | 1308 mA |
| Load torque | 0.1 mNm |
| Load speed | 37430 rpm |
| Load current | 200 mA |
| Max. output power | 1.0 W |
| Max. efficiency | 61.8 % |
| Back-EMF constant | 0.08 mV/rpm |
| Torque constant | 0.74 mNm/A |
| Speed/torque gradient | 45652 rpm/mNm |
| Rotor inertia | 0.016 g·cm² |
| Weight | 1.7 g |
| Operating temperature range | -20~+80 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L0614N5M67-500-3.2 |
|---|---|
| Voltage | 3.2 V |
| Terminal resistance | 1.70 Ω |
| No-load speed | 50000 rpm |
| No-load current | 80 mA |
| Stall torque | 1.1 mNm |
| Stall current | 1882 mA |
| Load torque | 0.1 mNm |
| Load speed | 45260 rpm |
| Load current | 250 mA |
| Max. output power | 1.4 W |
| Max. efficiency | 63.1 % |
| Back-EMF constant | 0.06 mV/rpm |
| Torque constant | 0.59 mNm/A |
| Speed/torque gradient | 47393 rpm/mNm |
| Rotor inertia | 0.016 g·cm² |
| Weight | 1.7 g |
| Operating temperature range | -20~+120 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
