Characteristics
| Parameter | Unit | VL1013N5M09-89-3.0 | VL1013N5M10-73-3.7 |
|---|---|---|---|
| Voltage | V | 3.0 | 3.7 |
| Terminal resistance | Ohm | 7.7 | 26.4 |
| Speed | rpm | 8900 | 7200 |
| Current | mA | 119 | 26 |
| Starting voltage | V | 0.8 | 0.8 |
| Stall current | mA | 380 | 140 |
| Weight | g | 6.1 | 7.8 |
| Operating temperature range | °C | -10～+65 | -10～+65 |
Applications
health care products
wearable products
mobile phones
tablet PC´s
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Parameter | Unit | VL1013N5M09-89-3.0 |
|---|---|---|
| Voltage | V | 3.0 |
| Terminal resistance | Ohm | 7.7 |
| Speed | rpm | 8900 |
| Current | mA | 119 |
| Starting voltage | V | 0.8 |
| Stall current | mA | 380 |
| Weight | g | 6.1 |
| Operating temperature range | °C | -10～+65 |
Applications
health care products
wearable products
mobile phones
tablet PC´s
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Parameter | Unit | VL1013N5M10-73-3.7 |
|---|---|---|
| Voltage | V | 3.7 |
| Terminal resistance | Ohm | 26.4 |
| Speed | rpm | 7200 |
| Current | mA | 26 |
| Starting voltage | V | 0.8 |
| Stall current | mA | 140 |
| Weight | g | 7.8 |
| Operating temperature range | °C | -10～+65 |
Applications
health care products
wearable products
mobile phones
tablet PC´s
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
