| Characteristics | L1215N5M43-230-6.0 | L1215N5M48-330-8.0 | L1215N5M34-280-6.0 |
|---|---|---|---|
| Voltage | 6.0 V | 8.0 V | 6.0 V |
| Terminal resistance | 3.4 Ω | 3.3 Ω | 2.3 Ω |
| No-load speed | 23000 rpm | 33000 rpm | 28000 rpm |
| No-load current | 50 mA | 80 mA | 70 mA |
| Stall torque | 4.1 mNm | 5.2 mNm | 5.1 mNm |
| Stall current | 1760 mA | 2420 mA | 2610 mA |
| Load torque | 1 mNm | 1 mNm | 0.5 mNm |
| Load speed | 20220 rpm | 29850 rpm | 25230 rpm |
| Load current | 260 mA | 300 mA | 320 mA |
| Max. output power | 2 W | 5 W | 3.7 W |
| Max. efficiency | 69.2 % | 67 % | 70 % |
| Back-EMF constant | 0.3 mV/rpm | 0.2 mV/rpm | 0.2 mV/rpm |
| Torque constant | 2.4 mNm/A | 2.2 mNm/A | 2.0 mNm/A |
| Speed/torque gradient | 5560 rpm/mNm | 6300 rpm/mNm | 5540 rpm/mNm |
| Rotor inertia | 0.1 g·cm² | 0.1 g·cm² | 0.1 g·cm² |
| Weight | 7 g | 7 g | 6.5 g |
| Operating temperature range | -20~+85 | -20~+85 | -20~+85 |
Applications
mini UAV
remote control hobby products
small household appliances
Produkt
| Specification | L1215N5M43-230-6.0 |
|---|---|
| Voltage | 6.0 V |
| Terminal resistance | 3.4 Ω |
| No-load speed | 23000 rpm |
| No-load current | 50 mA |
| Stall torque | 4.1 mNm |
| Stall current | 1760 mA |
| Load torque | 1 mNm |
| Load speed | 20220 rpm |
| Load current | 260 mA |
| Max. output power | 2 W |
| Max. efficiency | 69.2 % |
| Back-EMF constant | 0.3 mV/rpm |
| Torque constant | 2.4 mNm/A |
| Speed/torque gradient | 5560 rpm/mNm |
| Rotor inertia | 0.1 g·cm² |
| Weight | 7 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Produkt
| Specification | L1215N5M48-330-8.0 |
|---|---|
| Voltage | 8.0 V |
| Terminal resistance | 3.3 Ω |
| No-load speed | 33000 rpm |
| No-load current | 80 mA |
| Stall torque | 5.2 mNm |
| Stall current | 2420 mA |
| Load torque | 1 mNm |
| Load speed | 29850 rpm |
| Load current | 300 mA |
| Max. output power | 5 W |
| Max. efficiency | 67 % |
| Back-EMF constant | 0.2 mV/rpm |
| Torque constant | 2.2 mNm/A |
| Speed/torque gradient | 6300 rpm/mNm |
| Rotor inertia | 0.1 g·cm² |
| Weight | 7 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Produkt
| Specification | L1215N5M34-280-6.0 |
|---|---|
| Voltage | 6.0 V |
| Terminal resistance | 2.3 Ω |
| No-load speed | 28000 rpm |
| No-load current | 70 mA |
| Stall torque | 5.1 mNm |
| Stall current | 2610 mA |
| Load torque | 0.5 mNm |
| Load speed | 25230 rpm |
| Load current | 320 mA |
| Max. output power | 3.7 W |
| Max. efficiency | 70 % |
| Back-EMF constant | 0.2 mV/rpm |
| Torque constant | 2.0 mNm/A |
| Speed/torque gradient | 5540 rpm/mNm |
| Rotor inertia | 0.1 g·cm² |
| Weight | 6.5 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
