Description
Graphite Brush
| Specification | 2233N5C18-180-12.0 |
|---|---|
| Voltage | 12.0 V |
| Terminal resistance | 1.45 Ω |
| No-load speed | 18000 rpm |
| No-load current | 100 mA |
| Stall torque | 51.4 mNm |
| Stall current | 8280 mA |
| Nominal torque | 12.3 mNm |
| Nominal speed | 13700 rpm |
| Nominal current | 2060 mA |
| Max. output power | 24.3 W |
| Max. efficiency | 79 % |
| Back-EMF constant | 0.7 mV/rpm |
| Torque constant | 6.3 mNm/A |
| Speed/torque gradient | 350 rpm/mNm |
| Rotor inertia | 2.5 g·cm² |
| Weight | 52 g |
Applications
medical equipment and devices
healthcare products
automotive
robotics
industrial automation
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
