Description
Precious Metal Commutation
| Specification | 1027RFN31-17d-3.0 |
|---|---|
| Voltage | 3.0 V |
| Terminal resistance | 35/66 Ω |
| Speed | 13500 rpm |
| Current | 55 mA |
| Starting voltage | 2.3 V |
| Stall current | 90 mA |
| Operating temperature range | -20~+70 ℃ |
Applications
wearable products
mobile phones
tablet PCs
health care products
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
