| Specification | VL0614N5M51-102-3.0 | VL0614N5M17-150-1.5 | VL0614N5M41-71-1.3 |
|---|---|---|---|
| Voltage | 3.0 V | 1.5 V | 1.3 V |
| Terminal resistance | 18 Ω | 3.3 Ω | 8.1 Ω |
| Speed | 10200 rpm | 15000 rpm | 7100 rpm |
| Current | 50 mA | 100 mA | 50 mA |
| Starting voltage | 0.06 V | 0.6 V | 0.6 V |
| Stall current | 180 mA | 170 mA | 170 mA |
| Weight | 2.9 g | 2.25 g | 2.8 g |
| Operating temperature range | -10～+65 | -10～+65 | -10～+65 |
Applications
wearable products
mobile phones
tablet PC´s
health care products
VL0614N5M
| Specification | VL0614N5M51-102-3.0 |
|---|---|
| Voltage | 3.0 V |
| Terminal resistance | 18 Ω |
| Speed | 10200 rpm |
| Current | 50 mA |
| Starting voltage | 0.06 V |
| Stall current | 180 mA |
| Weight | 2.9 g |
| Operating temperature range | -10～+65 °C |
Applications
wearable products
mobile phones
tablet PC´s
health care products
VL0614N5M
| Specification | VL0614N5M17-150-1.5 |
|---|---|
| Voltage | 1.5 V |
| Terminal resistance | 3.3 Ω |
| Speed | 15000 rpm |
| Current | 100 mA |
| Starting voltage | 0.6 V |
| Stall current | 170 mA |
| Weight | 2.25 g |
| Operating temperature range | -10～+65 °C |
Applications
wearable products
mobile phones
tablet PC´s
health care products
VL0614N5M
| Specification | VL0614N5M41-71-1.3 |
|---|---|
| Voltage | 1.3 V |
| Terminal resistance | 8.1 Ω |
| Speed | 7100 rpm |
| Current | 50 mA |
| Starting voltage | 0.6 V |
| Stall current | 170 mA |
| Weight | 2.8 g |
| Operating temperature range | -10～+65 °C |
Applications
wearable products
mobile phones
tablet PC´s
health care products
