| Specification | VL0612N3M42-95-1.3 | VL0612N3M24-125-3.7 | VL0612N3M52-130-1.5 |
|---|---|---|---|
| Voltage | 1.3 V | 3.7 V | 1.5 V |
| Terminal resistance | 7.8 Ω | 26.4 Ω | 6.4 Ω |
| Speed | 9500 rpm | 12500 rpm | 13000 rpm |
| Current | 70 mA | 80 mA | 90 mA |
| Starting voltage | 0.8 V | 1.5 V | 0.8 V |
| Stall current | 200 mA | 200 mA | 200 mA |
| Weight | 2.3 g | 2.49 g | 2.1 g |
| Operating temperature range | -10～+65 | -10～+65 | -10～+65 |
Applications
wearable products
mobile phones
tablet PC´s
health care products
VL0612N3M
| Specification | VL0612N3M42-95-1.3 |
|---|---|
| Voltage | 1.3 V |
| Terminal resistance | 7.8 Ω |
| Speed | 9500 rpm |
| Current | 70 mA |
| Starting voltage | 0.8 V |
| Stall current | 200 mA |
| Weight | 2.3 g |
| Operating temperature range | -10～+65 °C |
Applications
wearable products
mobile phones
tablet PC´s
health care products
VL0612N3M
| Specification | VL0612N3M24-125-3.7 |
|---|---|
| Voltage | 3.7 V |
| Terminal resistance | 26.4 Ω |
| Speed | 12500 rpm |
| Current | 80 mA |
| Starting voltage | 1.5 V |
| Stall current | 200 mA |
| Weight | 2.49 g |
| Operating temperature range | -10～+65 °C |
Applications
wearable products
mobile phones
tablet PC´s
health care products
VL0612N3M
| Specification | VL0612N3M52-130-1.5 |
|---|---|
| Voltage | 1.5 V |
| Terminal resistance | 6.4 Ω |
| Speed | 13000 rpm |
| Current | 90 mA |
| Starting voltage | 0.8 V |
| Stall current | 200 mA |
| Weight | 2.1 g |
| Operating temperature range | -10～+65 °C |
Applications
wearable products
mobile phones
tablet PC´s
health care products
