SKA DDR
Stall Torque: 210 – 760 Nm
Peak Torque: 458 – 2400 Nm
Maxium Speed @ 230/400 Vac: 50-180/90-300 rpm
| Specification | SKA DDR 430.120.560.53 | SKA DDR 430.120.560.54 | SKA DDR 430.120.560.55 |
|---|---|---|---|
| Stall torque | 560 Nm | 560 Nm | 560 Nm |
| Peak torque | 1649 Nm | 1649 Nm | 1649 Nm |
| Stall current | 17.82 Arms | 10.7 Arms | 5.94 Arms |
| Peak current | 72.6 Arms | 43.5 Arms | 24.1 Arms |
| Maximum speed @230 Vac 3phase | 90 rpm | 50 rpm | – |
| Maximum speed @400 Vac 3phase | 150 rpm | 90 rpm | 50 rpm |
| Torque constant ± 5% | 22.7 Nm/Arms | 37.9 Nm/Arms | 68.4 Nm/Arms |
| Voltage constant ± 5% | 1900 Vrms/krpm | 3150 Vrms/krpm | 5700 Vrms/krpm |
| Phase/phase resistance ± 5% | 1.37 Ω | 2.42 Ω | 7.8 Ω |
| Phase/phase inductance | 26 mH | 57 mH | 183 mH |
| Electrical time constant | 19 msec | 23.6 msec | 23.5 msec |
| Thermal resistance | 0.17 °C/W | 0.17 °C/W | 0.17 °C/W |
| Family Specification | Produkt |
|---|---|
| Time Rating | Continous |
| Insulation Class | F |
| Poles | 56 |
| Insulation System UL/CSA | cURus, DV155JFile nr.:E216686 |
| Ambient temperature | 0 to 40 °C °C |
| Ambient humidity | 20 to 80 %RH (non condensing) |
| Thermal protection | PT 1000 |
| CE | certified |
| Family Overview | Produkt |
|---|---|
| Stall Torque | 560 Nm |
| Peak Torque | 1649 Nm |
| Maxium Speed @ 230/400 Vac | 50 – 90 rpm |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | SKA DDR 430.120.560.53 |
|---|---|
| Stall torque | 560 Nm |
| Peak torque | 1649 Nm |
| Stall current | 17.82 Arms |
| Peak current | 72.6 Arms |
| Maximum speed @230 Vac 3phase | 90 rpm |
| Maximum speed @400 Vac 3phase | 150 rpm |
| Torque constant ± 5% | 22.7 Nm/Arms |
| Voltage constant ± 5% | 1900 Vrms/krpm |
| Phase/phase resistance ± 5% | 1.37 Ω |
| Phase/phase inductance | 26 mH |
| Electrical time constant | 19 msec |
| Thermal resistance | 0.17 °C/W |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | SKA DDR 430.120.560.54 |
|---|---|
| Stall torque | 560 Nm |
| Peak torque | 1649 Nm |
| Stall current | 10.7 Arms |
| Peak current | 43.5 Arms |
| Maximum speed @230 Vac 3phase | 50 rpm |
| Maximum speed @400 Vac 3phase | 90 rpm |
| Torque constant ± 5% | 37.9 Nm/Arms |
| Voltage constant ± 5% | 3150 Vrms/krpm |
| Phase/phase resistance ± 5% | 2.42 Ω |
| Phase/phase inductance | 57 mH |
| Electrical time constant | 23.6 msec |
| Thermal resistance | 0.17 °C/W |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | SKA DDR 430.120.560.55 |
|---|---|
| Stall torque | 560 Nm |
| Peak torque | 1649 Nm |
| Stall current | 5.94 Arms |
| Peak current | 24.1 Arms |
| Maximum speed @230 Vac 3phase | – |
| Maximum speed @400 Vac 3phase | 50 rpm |
| Torque constant ± 5% | 68.4 Nm/Arms |
| Voltage constant ± 5% | 5700 Vrms/krpm |
| Phase/phase resistance ± 5% | 7.8 Ω |
| Phase/phase inductance | 183 mH |
| Electrical time constant | 23.5 msec |
| Thermal resistance | 0.17 °C/W |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
