| Specification | L0615N5M29-430-3.4 | L0615N5M35-387-2.5 | L0615N5M49-360-2.5 |
|---|---|---|---|
| Voltage | 3.4 V | 2.5 V | 2.5 V |
| Terminal resistance | 2.30 Ω | 1.45 Ω | 1.40 Ω |
| No-load speed | 43050 rpm | 38700 rpm | 36000 rpm |
| No-load current | 85 mA | 80 mA | 75 mA |
| Stall torque | 1.0 mNm | 1.0 mNm | 1.1 mNm |
| Stall current | 1478 mA | 1724 mA | 1786 mA |
| Load torque | 0.15 mNm | 0.15 mNm | 0.15 mNm |
| Load speed | 36530 rpm | 32700 rpm | 31030 rpm |
| Load current | 300 mA | 340 mA | 310 mA |
| Max. output power | 1.1 W | 1.0 W | 1.0 W |
| Max. efficiency | 57.8 % | 61.6 % | 63.3 % |
| Back-EMF constant | 0.07 mV/rpm | 0.06 mV/rpm | 0.07 mV/rpm |
| Torque constant | 0.71 mNm/A | 0.59 mNm/A | 0.64 mNm/A |
| Speed/torque gradient | 43485 rpm/mNm | 40021 rpm/mNm | 33119 rpm/mNm |
| Rotor inertia | 0.016 g·cm² | 0.016 g·cm² | 0.016 g·cm² |
| Weight | 1.8 g | 1.8 g | 1.8 g |
| Operating temperature range | -20~+120 | -20~+120 | -20~+120 |
Applications
mini UAV
remote control hobby products
small household appliances
L0615N5M
| Specification | L0615N5M29-430-3.4 |
|---|---|
| Voltage | 3.4 V |
| Terminal resistance | 2.30 Ω |
| No-load speed | 43050 rpm |
| No-load current | 85 mA |
| Stall torque | 1.0 mNm |
| Stall current | 1478 mA |
| Load torque | 0.15 mNm |
| Load speed | 36530 rpm |
| Load current | 300 mA |
| Max. output power | 1.1 W |
| Max. efficiency | 57.8 % |
| Back-EMF constant | 0.07 mV/rpm |
| Torque constant | 0.71 mNm/A |
| Speed/torque gradient | 43485 rpm/mNm |
| Rotor inertia | 0.016 g·cm² |
| Weight | 1.8 g |
| Operating temperature range | -20~+120 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
L0615N5M
| Specification | L0615N5M35-387-2.5 |
|---|---|
| Voltage | 2.5 V |
| Terminal resistance | 1.45 Ω |
| No-load speed | 38700 rpm |
| No-load current | 80 mA |
| Stall torque | 1.0 mNm |
| Stall current | 1724 mA |
| Load torque | 0.15 mNm |
| Load speed | 32700 rpm |
| Load current | 340 mA |
| Max. output power | 1.0 W |
| Max. efficiency | 61.6 % |
| Back-EMF constant | 0.06 mV/rpm |
| Torque constant | 0.59 mNm/A |
| Speed/torque gradient | 40021 rpm/mNm |
| Rotor inertia | 0.016 g·cm² |
| Weight | 1.8 g |
| Operating temperature range | -20~+120 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
L0615N5M
| Specification | L0615N5M49-360-2.5 |
|---|---|
| Voltage | 2.5 V |
| Terminal resistance | 1.40 Ω |
| No-load speed | 36000 rpm |
| No-load current | 75 mA |
| Stall torque | 1.1 mNm |
| Stall current | 1786 mA |
| Load torque | 0.15 mNm |
| Load speed | 31030 rpm |
| Load current | 310 mA |
| Max. output power | 1.0 W |
| Max. efficiency | 63.3 % |
| Back-EMF constant | 0.07 mV/rpm |
| Torque constant | 0.64 mNm/A |
| Speed/torque gradient | 33119 rpm/mNm |
| Rotor inertia | 0.016 g·cm² |
| Weight | 1.8 g |
| Operating temperature range | -20~+120 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
